DKM – Modular KVM Matrix Switching and Extension


Instantaneous HD and 4K KVM matrix switching for mission-critical installations

The DKM FX system enables flexible, instantaneous, and reliable matrix switching and extension of high-quality video, audio and peripheral signals. Choose from chassis-based, modular KVM matrix switches in multiple sizes, compact CATx and fiber switches, and DKM extenders. The proprietary signal transmission architecture of DKM matrix switches make them particularly well suited for mission-critical installations as their multi-level redundancy offers the highest reliability for 24/7 operation.


Digital KVM Matrix Switching


DKM Features

  • Modular, Flexible KVM Matrix Switching
    Choose from modular or compact chassis and extenders and add I/O cards that match your application requirements.

  • Dynamic I/O Ports for CATx or Fiber Cabling
    Enables mixing and matching of copper and fiber cabling to meet distance and media requirements

  • HD and 4K at 60 Hz Video Support
    Supports routing, switching, and multi-point distribution of various video, audio and peripheral signal types

  • Instantaneous Video Switching
    Instant, delay-free switching between multiple connected source computers for efficient multiuser access.

DKM Benefits


Highly Reliable

DKM is designed to perform at the highest standards, engineered for enterprise-level mission-critical 24/7 operations such as in control rooms.


Designed to Perform

Zero keyboard/mouse latency and instant switching between sources enable multi user access in real-time for the most demanding applications such as video editing.

Comprehensive Connectivity

Variety of Interface Cards

Supports I/O card-based high-speed USB, audio, serial, DVI, HDMI, DisplayPort, SDI, 3G-SDI, VGA, and other digital and analog standards.


Modular and Scalable

The modular architecture provides an easy way to add connections and change inputs/outputs as enterprise needs arise. Modular chassis available up to 576 ports (cascadable).


Extended Management Options

The included control card supports user-friendly management via KVM, network or serial console. Combine with Boxilla® KVM Manager to connect to an IP-based Emerald® KVM system.

Mixed Transmission Media

Mixed Transmission Media

Switch to and between CATx and fiber connections. Mix media on inputs and outputs, CATx in and fiber out or vice versa.

Industry Applications


Broadcast and Post Production

KVM systems that streamline your operational workflow and provide reliable image quality



Complete solutions for transportation, including DAS/Wi-Fi, cloud and digital signage



Contact us for DKM products that are certified under IEC 60945:2002 for maritime applications.


Military & Defense

Mission-focused technology solutions that meet security and compliance standards



Industrial networking solutions that ensure maximum uptime at every stage of production


Public Safety

Reliable solutions that provide effective real-time information visualization and communication

Case Studies Featuring DKM

French Television-Station Directly Transmit Lossless HD for Video from a Mobile Van Live to Air

Jan 12, 2013, 12:25 PM
A French TV station needed digital signal switching and extension for their mobile broadcast trucks. Black Box provided the DKM FX platform, supporting various devices, resolutions, and signal types with up to 500 meters of KVM-attached device support. The system ensures uninterrupted, high-quality broadcasting while on the move.
Title : French Television-Station Directly Transmit Lossless HD for Video from a Mobile Van Live to Air
Company : French Television Station
Company link :
Button :
External link :

The Challenge

Black Box France was contacted by French television stations located in Strasbourg and Toulouse to find a solution to add digital signal switching and extension in their new mobile broadcast trucks. The solution had to support different types of devices (CPU, servers, monitors, etc.) with different resolutions, refresh rates, and different signal types (analog and digital). Analog audio and USB had to be extended as well.

The trucks contain between 60 and 80 target devices all within a close distance to each other. Video extension needed to have a resolution of 1920 x 1200, with the quality of a direct connection, and instantaneous switching. The trucks are the interface between a live television show and the television uplink— the equivalent of mini-studios on the road. The solution needed to support the use of KVM-attached devices up to 500 meters from the truck.

The Solution

After Black Box demonstrated the DKM FX extension and switching platform, the customer realized that this was the solution they needed. The DKM FX system addressed each of the challenges. It was a single, modular answer to a multilayered application. An additional selling point is the longterm customer service and warranty support offered by Black Box. As a leading technology provider, Black Box offers much more than a simple transaction, including pre- and postsales engineering consultation, pre-staging of systems, onsite commissioning, training, and free, ongoing tech support.

Black Box engineers assisted the client throughout the design phase of the broadcast trucks, which enabled optimum integration of the DKM FX solution. Administrative and user trainings were also held during the integration with all personnel likely to use the DKM FX switching matrix. This yielded a comfortable and optimized workflow for production staff.

Today in France, two unique media trucks travel the roads, broadcasting news and television shows directly to studios without trouble or interruption.

DKM Features

The DKM HD Video and Peripheral Matrix Switch offers realtime switching and management of HD video, keyboards, mice, and other peripherals. No-loss video extension means a high-resolution end product. In broadcast, the DKM is perfect for managers and users of high-end editing and rendering computers and software. In this mobile broadcasting application, the DKM enables users to install a flexible, scalable system in a small space.

Tags :
  • Broadcast & Media
  • DKM
  • KVM Europe Middle East
  • KVM Matrix Switching
  • Media Production
  • TPS
Casestudy Hero Image - French OB-Vans - DKM Casestudy Thumbnail - French OB-Vans - DKM
Industry :
Solution :
Related pages :
Related pages :
Technology :
Load more comments

DKM Application Diagrams

DKM Matrix Switching Application


Basic matrix switching setup, connecting multiple user stations and source computers through a DKM matrix switch and DKM extenders.

Connecting DKM with Boxilla and Emerald


Integrating DKM with Boxilla and Emerald to gain access to an IP-based KVM system and virtual machines.

DKM Product Portfolio

The perfect high-performance, modular enterprise routing system for complete in-band signal distribution of high-definition video, audio, and peripherals over CATx or single-mode fiber supporting up to 576 I/O ports in a single frame. Designed with performance and flexibility in mind, the DKM FX offers tremendous scalability.
Specifically designed for smaller to mid-sized KVM deployments. Get the same instantaneous, reliable access to real-time digital HD video, plus a whole host of peripherals in a 1U or 2U frame for smaller installations. DKM FXC can be used with all DKM FX extender modules creating a wide range of high performance features and connections.
DKM Extenders
Re-locate computers and access them at longer distances than standard interconnect cables allow. Compact extenders are small and offer a space-saving footprint in standard fixed configurations. Modular extenders enable you to build a system to fit your specific need or application. Modular enclosure frames are available in 2-, 4-, 6-, and 21-slot units. The extenders can be used in standalone, point-to-point applications, or as part of your DKM system.
Specifically designed for smaller to mid-sized KVM deployments up to 160 endpoints, these compact switches come in sizes of 1, 2, and 4 RU. They support modern applications with a mix of HD and 4K video, USB, audio, and serial extension and switching in a very economical way.

DKM Extender Configurator

View Configurator

Associated Technologies


ControlBridge® KVM and Room Control System

Versatile touch-based multisystem room control processor. Allows control room operators to switch between sources or even whole room presets.


Freedom II KM Switches

This 4 or 8 port keyboard/mouse switch allows switching between connected PCs by just moving your mouse from one screen to another.


Boxilla KVM Manager

Boxilla is a centralized KVM manager. Combine DKM and Emerald systems to enable access to virtual machines.
