Emerald® PE KVM over IP トランスミッタ DVI-D・USB 2.0・オーディオ・RJ45およびSFPの冗長ネットワーク

ピクセルパーフェクトなHDビデオ、トランスペアレントなUSB 2.0、PoE、仮想マシン対応の IP KVM トランスミッタ / レシーバ

製品特徴

次世代のKVM延長技術とマトリックススイッチングにより、物理・仮想サーバーへのアクセスがより簡単に
最大1920×1080のピクセルパーフェクトなHD DVI映像に対応
USB HIDデバイス、透過型USB 2.0接続、および音声機能に対応しています
受信機のOSDまたはBoxillaから、帯域幅やユーザーアクセスの管理、新規エンドポイントの展開、ファームウェアの更新などを一括操作可能
DKMやBoxillaなど、既存のKVMシステムとの互換性あり
Connection Folders - organize, group, and manage connections for faster navigation and streamlined workflows
Centralized control with Boxilla® resilience
Dual network ports for fail-safe 24/7 uptime

Industry-Leading KVM
Emerald® PE provides users with a seamless desktop experience anywhere on a TCP/IP network while allowing the actual hardware to be stored in a corporate data center or in the cloud. This robust solution is easy to deploy on standard corporate networks and even across WANs. PE enables the same experience of a desktop PC even for media-rich applications, like video and photo editing.

Emerald PE supports multiple setups: It allows you to link transmitters and receivers in a point-to-point KVM extension over CATx up to 100 meters or even farther using an IP or WAN connection. Or connect multiple transmitters and receivers to an Emerald or IP switch to create a matrix switching setup.

Your Emerald KVM network may start small with a point-to-point extension, but it's infinitely scalable to meet your future needs just by adding endpoints, with no extra chassis or cards required. PE supports up to 32 endpoints with no additional KVM management appliance. For larger deployments, use Boxilla® to manage your enterprise KVM network centrally.

Headache-Free Migration and Scaling
Emerald makes your migration painless, enabling you to scale access infinitely and gradually across buildings, campuses, and more using your existing network infrastructure.

Outstanding Video Quality
Emerald PE supports pixel-perfect HD DVI video with resolutions up to 1920 x 1080. This makes it an ideal solution for applications that require the highest video quality, like medical imaging and control rooms.

Virtualization Support
Emerald PE simplifies access to both physical and virtual servers with high-performance connectivity to virtual machines, supporting VMware® and Microsoft® HyperV®, using RDP 8.1 and RemoteFX.

Simple System Management
Manage bandwidth and user access, deploy new endpoints, UPDATE firmware, and more. Emerald PE can be managed via the receiver's OSD or the central KVM management platform Boxilla. Boxilla is a hardware-based management appliance that features a user-friendly, browser-based GUI.

Fail-Safe Operation
Your 24/7 operation requires network resilience. Use the redundant network ports on the Emerald PE units to provide continuous, uninterrupted operation in the event one network experiences loss of service. Connect the endpoints through either two alternative direct links, a direct link, and a network connection or two independent networks.

Power
Emerald PE supports powering receiver units via an external PSU.

Works Perfectly with Other KVM Systems
Emerald works seamlessly with the rest of the Emerald product family and these popular Black Box KVM product families:

DKM proprietary, direct-connect KVM system
Freedom II Multi-Monitor Switch with Glide and Switch technology
ControlBridge, our system for one-touch, multisystem control
Boxilla KVM Manager

Product Includes:

すべてのトランスミッター

（1）Emerald PE トランスミッター（シングルヘッドまたはデュアルヘッド）
（1）12V DC 電源および電源コード
（1）DVI ケーブル（シングルヘッドの場合）または（2）DVI ケーブル（デュアルヘッドの場合）
（1）USB 2.0 Type B ケーブル

NOTE(s):

互換性に関する注意事項:

EmeraldPE_Firmware_v6.0 は、他のバージョン6.0のエンドポイントとのみ使用してください。
RemoteApp 2.1 は Firmware 6.0 と併用する必要があり、5.6とは互換性がありません。
5.2.9以前のファームウェアを使用しているユニットは、PEとの通信ができません。
5.2.9ファームウェアは、5.6および6.0ファームウェアと互換性がありません。

* Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 1-877-877-2269.
