USB-Powered 10/100 8-Port Switch

Powered through a PC's USB port, so there's no need to find a spare power outlet.

LBS008A

Extended Double Diamond™ Warranty Available
(3 Additional Year)

Product Highlights

  • 10-/100-Mbps ports are autosensing for speed and duplex.
  • A quick way to build a small network or add ports to an existing network.
  • Can be powered through a PC's USB port so there's no need to find a spare outlet. Or use the included AC power supply.
  • Auto MDI/MDI-X.


  • Description

    USB-Powered 10/100 8-Port Switch


    Quick Facts

  • 10-/100-Mbps ports are autosensing for speed and duplex.
  • A quick way to build a small network or add ports to an existing network.
  • Can be powered through a PC's USB port so there's no need to find a spare outlet. Or use the included AC power supply.
  • Auto MDI/MDI-X.

  • Further Details

    The compact USB-Powered 10/100 Switch is an easy way to quickly add eight 10-/100-Mbps Ethernet ports to your network. Because it's USB powered, you can plug it into the nearest PC—an advantage anywhere power outlets are tight.

    The switch offers autosensing 10-/100-Mbps ports that autonegotiate half-/full-duplex. All ports feature Auto MDI/MDI-X, so there's no need for cross-pinned cables—just plug it in and you're ready to go. There's no easier way to set up a quick workgroup. Plus, the switch is tiny enough to tuck neatly behind a PC.

    NOTE: 5-port version also available (LBS005A).


    Technical Specifications for USB-Powered 10/100 8-Port Switch:

    Environmental Operating temperature: 32 to 131° F (0 to 55° C);
    Operating humidity: 10-90%, noncondensing
    Filtering and Forwarding Rate 10 Mbps: 14,880 pps; 100 Mbps: 148,800 pps
    MAC Addresses 1K
    Standards IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-T, IEEE 802.3x flow control
    Switching Method Store-and-forward
    CE Approval Yes
    RoHS Yes
    Connectors (8) RJ-45, (1) Power
    Indicators LEDs: Per Unit: (1) Power; Per Port: (1) LINK/ACT
    Power From computer's USB port via power cable (included) or 115-VAC, 60-Hz external power supply (included);
    3 watts maximum
    Dimensions 0.8"H x 2.4"W x 3.1"D (2 x 6.2 x 7.9 cm)


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for USB-Powered 10/100 8-Port Switch:

    Manuals

    • USB-Powered 10/100 Switch User Manual
      User Manual for the LBS005A & LBS008A (Version 2)

    Visio Stencils

    • Visio Stencil
      Stencil Drawings
