MT651C

Photo may show similar product

Other views

T1/E1 Fiber Optic Line Driver Rackmount Card, ST, 850-nm Multimode

Extend T1/E1 lines from demarcation all the way to your equipment.

MT651C

Extended Double Diamond™ Warranty Available
(3 Additional Year)

Product Highlights

  • Multimode models use a VCSEL light source and send data up to 4.3 miles (7 km).


  • Description

    T1/E1 Fiber Optic Line Driver Rackmount Card, ST, 850-nm Multimode


    Quick Facts

  • Multimode models use a VCSEL light source and send data up to 4.3 miles (7 km).

  • Further Details

  • Converts T1 or E1 signals to fiber optic pulses.
  • Provides high speed with security.
  • Supports AMI, B8ZS, and HDB3 line codes.

  • Save money and extend your T1/E1 links yourself without losing speed, clarity, or data integrity!

    The phone company brings a T1 or E1 line to your building and terminates it. That's called the demarcation point. For a price, they'll extend the line from there to your T1 or E1 equipment. Or you can do it yourself with a Fiber Optic Line Driver. Get the extra distance you need and immunity to electrical noise and surges with fiber cable.

    These drivers convert T1's or E1's electrical signals to fiber optic light pulses and maintain the speed, clarity, and data integrity of your T1 or E1 line. Framing transparency and selectable options enable transmission with AMI, HDB3, or B8ZS signals.

    Our T1/E1 Fiber Optic Line Drivers also enable you to switch between T1 and balanced or unbalanced E1. Choose from standalone or card models.
    NOTE: Single-mode versions also available.

    NOTE: Must be used in pairs.


    Technical Specifications for T1/E1 Fiber Optic Line Driver Rackmount Card, ST, 850-nm Multimode:

    Approvals CE
    Distance 4.3 miles (7 km) maximum
    Speed 1.544 Mbps or 2.048 Mbps
    Interface DSX-1, G.703 balanced or unbalanced; 75, 100, or 120 ohms, jumper-selectable
    Connectors (1) DB15 F, (2) BNC F, (1) pair of ST®
    Power From the rack (RM110A)
    Dimensions 0.9"H x 6.2"W x 9"D (2.3 x 15.7 x 22.9 cm)

    NOTE: Must be used in pairs.

    This product works with:
  • Ceramic Multimode Fiber Optic Patch Cable, ST–ST (EFN110)
  • Single-Mode Duplex Fiber Optic Cable, ST–ST (EFN5009)
  • T1 Cable, Straight-Pinned, RJ-48C/RJ-48C (ETNMRS01)
  • RackNest 2/14 (RM110A, RM110AE)
  • RackNest 2/14 (RM110A)
    Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.

  • Resources for T1/E1 Fiber Optic Line Driver Rackmount Card, ST, 850-nm Multimode:
