Cabinets & Racks > Wallmount & Specialty Cabinets

click photo to enlarge

RM610A

Photo may show similar product

Other views

Server Side-Mount Wall Cabinet

Save space when mounting servers in long or narrow rooms.

RM610A


Lifetime Warranty

Product Highlights

  • Weight capacity of 350 pounds (158.7 kg) when secured to three wall studs.
  • Unique low-profile server-mount design enables you to mount servers sideways and get more servers in a tighter space!
  • Mesh doors ensure optimal airflow to keep hard-working servers cool.
  • Guaranteed for life!

  • Description

    Server Side-Mount Wall Cabinet


    Quick Facts

  • Weight capacity of 350 pounds (158.7 kg) when secured to three wall studs.
  • Unique low-profile server-mount design enables you to mount servers sideways and get more servers in a tighter space!
  • Mesh doors ensure optimal airflow to keep hard-working servers cool.
  • Guaranteed for life!

  • Further Details

  • For convenient access, just open the side doors to expose server controls and cable connections at the rear of mounted servers.
  • The 10U cabinet has 34" of usable space with a maximum of 29" of front-to-rear spacing*.
  • Flexible cable routing. Concentric knockouts at the top, bottom, and rear enable you to easily run 1", 2", and 3" conduit to mounted equipment.
  • Designed for easier wall hanging with three studs mounted on 16" centers.
  • Left- and right-side doors, as well as the front panel, can be locked to safeguard your expensive servers and prevent tampering by unauthorized personnel.
  • Includes a package of M6 cage nuts and screws.
  • UL® and cUL Listed.

  • Don’t sidestep around a cabinet sticking out 3 or 4 feet from the wall. Use this smartly designed 10U server cabinet instead and keep your pathways clear.

    * NOTE: At 29" rail spacing, the cabinet provides 2" of space in the front and 3" in the rear. The 10U of space isn't possible with all equipment configurations. For example, if you mount a 29" server in the cabinet, the maxium space is 8 RU because of the necessary rail adjustments.


    Technical Specifications for Server Side-Mount Wall Cabinet:

    Size — 24"H x 20.5"W x 36.1"D (61 x 52.1 x 91.4 cm)
    Weight — 100 lb. (45.4 kg)
    * NOTE: At 29" rail spacing, the cabinet provides 2" of space in the front and 3" in the rear. The 10U of space isn't possible with all equipment configurations. For example, if you mount a 29" server in the cabinet, the maxium space is 8U because of the necessary rail adjustments.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for Server Side-Mount Wall Cabinet:

    Product Data Sheets


    Connect your Server Side-Mount Wall Cabinet with:

    Accessory: RM386

    Wallmount Cabinet Dual-Fan Kit

    Wallmount Cabinet Dual-Fan Kit

    Accessory: RMT355A-R2

    Low-Profile Side Wallmount Cabinet, 2U

    Low-Profile Side Wallmount Cabinet, 2U
