KV6616FA

Photo may show similar product

Other views

ServSwitch Duo USB KVM Switch - 2 x 16

16 multiplatform servers can be accessed by 2 users with USB-style keyboards and mice.

KV6616FA

Extended Double Diamond™ Warranty Available
(3 Additional Year)

Product Highlights

  • Supports Sun® USB-style keyboards and mice.
  • High video resolution support. Maximum resolution is 1920 x 1440 @ 100 Hz.
  • DCC support.
  • Can be cascaded with the ServSwitch Duo.


  • Description

    ServSwitch Duo USB KVM Switch - 2 x 16


    Quick Facts

  • Supports Sun® USB-style keyboards and mice.
  • High video resolution support. Maximum resolution is 1920 x 1440 @ 100 Hz.
  • DCC support.
  • Can be cascaded with the ServSwitch Duo.

  • Further Details

  • Built-in DDC support.
  • On-screen menus enable easy switching.
  • You can also switch ports via a three-button mouse, an IntelliMouse, hotkey sequences, or the front-panel push buttons.

  • USB keyboard and mouse users can access and control up to hundreds of servers with these KVM switches!

    With a ServSwitch Duo™ USB, 2 users can access 16 servers—or up to hundreds of servers—if you daisychain multiple ServSwitch Duo USB units together or in series with multiple ServSwitch Uno™, ServSwitch Uno USB, or ServSwitch Duo!

    Built-in DDC support.
    DDC support enables a control station's monitor to communicate with the attached servers' video cards and configure their video drivers automatically at bootup.

    The ease of on-screen menus.
    On-screen menus pop up on demand and make it simple to select a server. Give each server a name that makes sense to you. No software is required on your servers; their names are stored in the switch's memory.

    Plus, you can use the on-screen menus to control who can access each server. Set a user's level of access to exclusive use, shared use, or video only.

    Select servers at your fingertips, too.
    You can also switch between servers via a three-button mouse, an IntelliMouse®, hotkey sequences, or the front-panel push buttons.

    More compatibility than the basic Duo.
    Like the basic ServSwitch Duo, the ServSwitch Duo USB supports a wide range of PC-compatible hardware and software platforms, including some high-end IBM® PS/2® compatible computers such as IBM RS/6000®, Compaq®, Alpha®, and SGI™.

    However, the ServSwitch Duo USB also works with USB keyboards and mice. Plus automatic mouse conversion means they work with all PS/2, IntelliMouse, and RS-232 mice. You can even mix both styles in one installation!

    For connecting remotely to your server room over IP, add the ServSwitch Wizard™ IP (ACR2004A) to control PC, Sun®, and Mac® servers.

    Scan servers at your own pace.
    Monitor all connected servers with autoscan. You can also scan only active servers attached to one chassis or selected servers attached to any chassis in your system. Program your preferred scan rate and view each server at your own pace.


    Technical Specifications for ServSwitch Duo USB KVM Switch - 2 x 16:

    Approvals CE
    Controls On-screen menus;
    Keyboard commands;
    Mouse-click functions: (2) push buttons for user and server selection;
    (1) DIP switch for firmware upgrade
    Distance User ports to any directly attached user station or KVM switch: 16.4 ft. (5 m) maximum;
    Server ports to any directly attached CPU or KVM switch: 35 ft. (10.6 m) maximum using EHN428-EHN429
    Video Resolution: 1920 x 1440 at 100 Hz maximum;
    DDC support: 1 and 2
    Interface Keyboard and mouse: USB only;
    Serial: Subset of TIA-574 (IBM PC DB9) pinout of TIA/EIA RS-232; USB and Sun with appropriate converter cables
    Connectors Power: (1) barrel jack;
    Serial: All: (1) DB9 F serial port for flash upgrade;
    User ports: (2), each consisting of: (1) HD15 F for monitor,
    (2) USB Type A F for keyboard and mouse;
    Server: (8) or (16), each consisting of: (1) HD15 F for video-port attachment, (2) 6-pin mini DIN F for keyboard and mouse
    Power External 100-240 VAC, 50-60 Hz, autosensing
    Dimensions 3.5"H (2U) x 17.3"W x 8.7"D (8.9 x 43.9 x 22.1 cm)

    NOTE: To connect Macintosh® CPUs, call our FREE Tech Support.

    This product works with:
  • CPU Cables for Standard KVM Connections (EHN408)
  • Control Station Cables (EHN409)
  • PS/2 to USB Flash Cables (EHN428)
  • ServSwitch Wizard IP (ACR2004A)
  • ServSwitch Uno (KV6016FA-R2)
  • ServSwitch Duo (KV6104SA-R2, KV6108SA-R2, KV6112FA-R2, KV6116FA-R2)
    Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.
