Mini Fiber Transceiver, ST

Make the perfect LAN connection with transceivers from Black Box.

LE2051A-ST-R4

Extended Double Diamond™ Warranty Available
(3 Additional Year)

Product Highlights

  • Features AUI DB15 and ST connectors.
  • Connect Ethernet devices to fiber segments.
  • Compact and lightweight for easy placement.
  • Diagnostic LEDs simplify monitoring and troubleshooting.


  • Description

    Mini Fiber Transceiver, ST


    Quick Facts

  • Features AUI DB15 and ST connectors.
  • Connect Ethernet devices to fiber segments.
  • Compact and lightweight for easy placement.
  • Diagnostic LEDs simplify monitoring and troubleshooting.

  • Further Details

    Mini FOIRL LD Transceiver
    The Mini FOIRL LD Transceiver offers excellent link fault detection. Any standard hub connected to one of these transceivers can detect faults on both the hub and transceiver sides of the link. Use this transceiver to build an EMI-resistant FOIRL that extends up to 1.2 miles (2 km).

    Slim AUI connectors enable you to attach transceivers directly to the AUI port on most CPUs without extra cable.

    Mini Fiber Transceiver
    The Mini Fiber Transceiver plugs right into your workstation—even in a tight space without extra AUI cable. Plus, this transceiver resists EMI!

    This 10-Mbps 10BASE-FL transceiver has a DB15 male locking-post AUI connector at one end and two ST receptacles at the other. It enables you to make quick, easy plug-and-twist connections to a multimode fiber interrepeater link up to 1.2 miles (2 km) long.

    Micro Single-Mode Fiber Transceiver
    The Micro Single-Mode Fiber Transceiver connects Ethernet units directly to your single-mode 10BASE-FL or FOIRL network. It uses a 1300-nm wavelengths and supports up to 4.9 miles (8 km) over single-mode fiber.

    The transceiver's DB15 connector's locking-post design ensures a reliable link.


    Technical Specifications for Mini Fiber Transceiver, ST:

    Connectors (1) DB15 M, (1) pair of ST
    Indicators (7) LEDs: JAB, Link, TX, RX, COL, SQE, Power
