Networking > SOHO

click photo to enlarge

LEP0000A-R3

Photo may show similar product

Other views

Mini 10/100 Print Server, Parallel, 1-Port

Here’s a low-cost way to give your network users access to a parallel printer on your network.

LEP0000A-R3

Extended Double Diamond™ Warranty Available
(Three years for two)

Product Highlights

  • Gives your network users access to a parallel printer on your network.
  • Communicates with the printer just as if it's directly connected to your computer.
  • All users can access print, scan, card reader, and fax functions via the network.
  • One-port, mini-size form factor. Ideal for compact installations involving only one printer.

  • Description

    Mini 10/100 Print Server, Parallel, 1-Port


    Quick Facts

  • Gives your network users access to a parallel printer on your network.
  • Communicates with the printer just as if it's directly connected to your computer.
  • All users can access print, scan, card reader, and fax functions via the network.
  • One-port, mini-size form factor. Ideal for compact installations involving only one printer.

  • Further Details

  • Supports bidirectional communications. Monitor toner and paper levels on the printer remotely.
  • Also enables you to share a printer with your remote users via an Internet connection.
  • Complies with IEEE 802.3/802.3u standards.
  • Compatible with most popular MFP printers.
  • Supports LPR, IPP, and RAW printing protocols, plus DHCP client protocols.
  • Works with Windows® 2000, Windows XP, andWindows Vista® PCs, as well as Mac® computers running OS 10.4.x and above.
  • Supports Auto MDI/MDI-X on its 10-/100-Mbps RJ-45 port.
  • Easy to set up.
  • Supports Web-based management and includes admin and firmware upgrade utilities.
  • RoHS compliant.

  • This tiny print server enables you to share a parallel printer on your network. It's just what you need to provide easy access to a high-end printer by multiple users on your LAN.

    The 1-Port 10/100 Print Server, Mini is particularly ideal for office or department users who need access to the print, scan, card readers, and fax functions of a shared printer.

    This print server supports a number of printing protocols, including LPR, IPP, SMB/TCP, and RAW printing. What’s more, it works with most printers on the market today, including Brother®, Canon®, EPSON®, HP®, Lexmark®, and others (for a full list of compatible printers, contact our FREE Tech Support).

    Because it’s compatible with TCP/IP, IPX/SPXTM, and other network protocols, the print server is easy to integrate into any network environment. The UTP port complies with IEEE802.3 and 802.u for Ethernet and Fast Ethernet connections, and it supports Auto MDI/MDI-X for simplified crossover or straight-pinned cabling.

    Because the print server supports bidirectional communications, you can troubleshoot your printer operation over a TCP/IP network connection.

    For easy setup, the 1-Port 10/100 Print Server, Mini comes with a CD-based utility that includes a user-friendly installation wizard for simplified configuration and management. To configure and manage the server via a TCP/IP connection, just install the included Web manager utility. It enables you to access the print server by entering its IP address into your browser’s address field.

    Flash memory enables convenient upgrades to the print server. It even has a fault-tolerant upgrade function, which enables you to “re-upgrade" the device if problems occur during the initial or previous upgrade session.


    Technical Specifications for Mini 10/100 Print Server, Parallel, 1-Port:

    Memory — Flash: 512 MB;
    RAM: 2 MB SDRAM
    Standards — IEEE 802.3, IEEE 802.3u
    Operating Systems —  Compatible with Windows 98SE, Me/NT/2000, XP, 2003, Vista; Unix; Linux; Mac OS 9.x and above
    CE Approval — Yes
    RoHS — Yes
    Connectors — Printer port: (1) Centronics® M;
    LAN port: (1) RJ-45 (10/100 Mbps)
    Indicators — LEDs: (1) Ready, (1) Status, (1) LAN
    Power — Input: 120 VAC, 60 Hz external power supply
    Size — 0.9"H x 2.4"W x 3"D (2.3 x 6.1 x 7.6 cm)


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.
