Datacom > Modems & CSUs

click photo to enlarge

MT1511A

Photo may show similar product

Other views

Managed T1/FT1 CSU/DSUs, V.35 with DSX

These managed CSU/DSUs process high-speed T1 data and share bandwidth, too.

MT1511A

Extended Double Diamond™ Warranty Available
(Three years for two)

Product Highlights

  • High reliability.
  • Comply with full and fractional T1, and they support Frame Relay services.

  • Description

    Managed T1/FT1 CSU/DSUs, V.35 with DSX


    Quick Facts

  • High reliability.
  • Comply with full and fractional T1, and they support Frame Relay services.

  • Further Details

  • Include a DB9 SNMP port.
  • DSX (drop and insert) model (MT1511A) enables you to connect to a PBX and share voice/data bandwidth.
  • All models include a DB9 (DCE) console port and have a V.35 female connector.
  • All include (1) 6-foot (1.8-m) RJ-48C cable.


  • Our Managed T1/FT1 CSU/DSUs (MT1510A-35, MT1511A, MT1510A-530) feature a single V.35 data port as well as an RS-232 console port. Plus, they come with a separate SNMP management port. Complete SNMP management with real-time alarm messages can be delivered to SNMP managers.

    The Managed T1/FT1 CSU/DSU with DSX (MT1511A) also has a DSX port that enables you to configure your T1 line to share bandwidth capacity for voice and data.

    All three managed CSU/DSUs feature critical information displayed with date- and time-stamped alarm information. Their menu structure enables easy setup and diagnostic testing from any VT100™ compatible device.


    Technical Specifications for Managed T1/FT1 CSU/DSUs, V.35 with DSX:

    Command Mode — Console, SNMP, LCD/front panel
    Framing — D4/ESF selectable
    Line Coding — AMI/B8ZS selectable
    Line Rate — 1.544 Mbps
    Network Line Interface — T1
    SNMP Protocol — SLIP
    Connectors — MT1510A-35, MT1511A: (1) RJ-48C, (1) V.35 F, (2) DB9 F ([1] console, [1] SNMP management);
    MT1510A-530: (1) RJ-48C, (1) M/34 F, (2) DB9 F ([1] console, [1] SNMP management)
    Temperature Tolerance — Operating: (0 to 40° C);
    Storage: (-20 to +70° C)
    Humidity Tolerance — 95%, noncondensing
    Power — Input: 120 VAC, 60 Hz, 19 W;
    Output: 12 VAC, 1800 mA
    Size — 2.3"H x 8.5"W x 11.3"D (5.8 x 21.6 x 28.7 cm)
    Weight — 7 lb. (3.2 kg)
    NOTE: For rackmount and DC versions, contact our FREE Tech Support.

    These products work with:
  • V.35 Interface Cable, Male/Female (EYN450T-MF)
  • DB9 Extension Cable (with EMI/RFI Hoods) (EDN12H)
  • RS-530 Data Cable, Male/Female (EVN530T-MF, EVN530-MF)
  • Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for Managed T1/FT1 CSU/DSUs, V.35 with DSX:


    Connect your Managed T1/FT1 CSU/DSUs, V.35 with DSX with:

    Double Diamond Warranty

    Standard Manufacturer's Warranty


    A One year warranty is included.

    Extended Two years for one Warranty Available


    Protect your purchase with an additional Two years for oneDouble Diamond™ warranty!
    Cost: $126.00

    Extended Three years for two Warranty Available


    Protect your purchase with an additional Three years for twoDouble Diamond™ warranty!
    Cost: $251.99

    Diamond

    Double Diamond™ Warranty (Standard)

    Coverage:

    The most complete product warranty exclusively from Black Box

    The Double Diamond™ Warranty is our no-questions-asked warranty that protects your Black Box® brand products* from accidental damage, including drops, water, and power surges.

    Most products come with a one- or two-year warranty. Some products, such as copper cables, manual switches, cabinets, and racks, are guaranteed for life! Standard Warranty features are as follows:

    Worry-Free Purchases

    If your new Black Box® brand products are accidentally damaged, you're covered with this no-questions asked warranty. FREE

    Coverage

    Double Diamond™ is the standard warranty that comes with your new Black Box® brand product. Most products come with a one- or two-year warranty.

    Lifetime Guarantees

    Many products, such as copper cables, manual switches, cabinets, and racks, are guaranteed for life.

    Fast Service

    During the warranty period, Black Box® Network Services will repair or replace your damaged equipment within one week of receipt at NO CHARGE!

    Extra Coverage

    Extend your warranty or protect a previously purchased Black Box® brand product* for an additional year for only 10% of the current retail price! And when you do, we give you the second year of extended coverage free! FREE Tech Support Hotline. No cost. No contracts. No kidding!

    No-Risk 45-Day Return Policy

    If it's not right, send it back.
    (Excludes custom built products)

    * Certain products may not be eligible.

    Warranty Compared

    Black Box® Double Diamond™ Warranty The Competition
    Warranty Length One Year to Lifetime, Depending on the Product. Read the fine print.
    Guaranteed for Life! Black Box® Brand Copper Cables, Manual Switches and More! No.
    Accidental Damage 100% Covered! No.
    Water Damage 100% Covered! No.
    Power Surges 100% Covered! No.
    Warranty Replacements No Questions Asked! Forget It.
    Tech Support Hotline 100% FREE! $$$
    Product SKU Price Quantity
    Managed T1/FT1 CSU/DSUs, V.35 with DSX MT1511A $1,259.95

    Managed T1/FT1 CSU/DSUs, V.35 MT1510A-35 $1,102.95

    Managed T1/FT1 CSU/DSUs, RS-530 MT1510A-530 $1,102.95
