Networking > Industrial

click photo to enlarge

LMM116A

Photo may show similar product

Other views

Managed Miniature Media Converter, 10-/100-Mbps Copper to 100-Mbps Single-Strand, Single-Mode Fiber, 1550-nm TX/1310-nm RX, 20 km, SC

The compact media converter with full SNMP management and PoE.

LMM116A

Extended Double Diamond™ Warranty Available
(Three years for two)

Product Highlights

  • Bring the convenience of SNMP management even to remote network nodes.
  • Perfect for use as a remote unit with our High-Density Media Converter System II.
  • Full SNMP management for configuring and monitoring remote links.
  • Sends and receives on a single fiber strand, so you save on infrastructure costs.
  • Bidirectional bandwidth control enables you to manage network traffic flow.


    • Description

    Managed Miniature Media Converter, 10-/100-Mbps Copper to 100-Mbps Single-Strand, Single-Mode Fiber, 1550-nm TX/1310-nm RX, 20 km, SC


    Quick Facts

  • Bring the convenience of SNMP management even to remote network nodes.
  • Perfect for use as a remote unit with our High-Density Media Converter System II.
  • Full SNMP management for configuring and monitoring remote links.
  • Sends and receives on a single fiber strand, so you save on infrastructure costs.
  • Bidirectional bandwidth control enables you to manage network traffic flow.

    • Further Details

  • This Layer 2 media converter features IEEE 802.1Q VLAN tags with Q-in-Q tagging (802.1ad) and QoS-IEEE 802.1p-based packet prioritization.
  • Auto MDI/MDI-X on the copper port so you never need a cross-pinned cable.
  • Autonegotiates for speed and duplex on the copper port.
  • Supports oversized packets up to 1916 bytes.
  • Includes loopback test modes plus LinkLoss™ and FiberAlert™.
  • Powered three ways: with the included AC power adapter, a 4-terminal DC power block, or Power over Ethernet (PoE).
  • Includes clips for DIN rail mounting.

    • NOTE: This converter must be used in matched pairs along with its companion converter (LMM115A) or High-Density Media Converter System II module (LMC5123C-R3). Order one of each. For details, contact our FREE Tech Support.

    This product works with:
    Managed Miniature Media Converter, 10-/100-Mbps Copper to 100-Mbps Single-Strand, Single-Mode Fiber, 1550-nm TX/1310-nm RX, 20 km, SC (LMM115A).
  • High-Density Media Converter System II Layer 2 Module, 10BASE-T/100BASE-TX to 100BASE-FX, Single-Strand, Single-Mode, 1550-nm-TX/1310-nm RX, SC, 20 km (LMC5123C-R3)
    Questions? Contact our FREE Tech Support.


    • Technical Specifications for Managed Miniature Media Converter, 10-/100-Mbps Copper to 100-Mbps Single-Strand, Single-Mode Fiber, 1550-nm TX/1310-nm RX, 20 km, SC :

    Management — SNMP V1 and V2c compatible
    CE Approval — Yes
    Power — AC wall adapter: 100/240 VAC, 50/60 Hz input, 5 VDC output;
    DC input voltage: 750 mA at 5 V, extended voltage range of 5–50 VDC;
    IEEE 802.3af inline PoE power injector
    Size — 0.8"H x 1.8"W x 3.4"D (2 x 4.6 x 8.6 cm)
    Weight — 0.3 lb. (0.1 kg)

    This product works with:
    Managed Miniature Media Converter, 10-/100-Mbps Copper to 100-Mbps Single-Strand, Single-Mode Fiber, 1550-nm TX/1310-nm RX, 20 km, SC (LMM115A).
  • High-Density Media Converter System II Layer 2 Module, 10BASE-T/100BASE-TX to 100BASE-FX, Single-Strand, Single-Mode, 1550-nm-TX/1310-nm RX, SC, 20 km (LMC5123C-R3)
    Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    • Resources for Managed Miniature Media Converter, 10-/100-Mbps Copper to 100-Mbps Single-Strand, Single-Mode Fiber, 1550-nm TX/1310-nm RX, 20 km, SC :

    Manuals

    • Managed Miniature Media Converters User Manual
      User Manual for the LMM101A-R2, LMM102A-R2, LMM103A-R2, LMM104A-R2, LMM115A, and LMM116A (Version 2)
      httpftp
    • Managed Miniature Media Converter User Manual
      User Manual for Managed Miniature Media Converter (1)
      httpftp

    Quick Start Guides

    • Managed Miniature Media Converter Quick Start Guide
      Quick Start Guide for Managed Miniature Media Converter (1)
      httpftp

    Black Box Explains


    Connect your Managed Miniature Media Converter, 10-/100-Mbps Copper to 100-Mbps Single-Strand, Single-Mode Fiber, 1550-nm TX/1310-nm RX, 20 km, SC with:

    Accessory: LMM115A

    Managed Miniature Media Converter, 10-/100-Mbps Copper to 100-Mbps Single-Strand, Single-Mode Fiber, 1310-nm TX/1550-nm RX, 20 km, SC

    Managed Miniature Media Converter, 10-/100-Mbps Copper to 100-Mbps Single-Strand, Single-Mode Fiber, 1310-nm TX/1550-nm RX, 20 km, SC

    » more info

    Accessory: LMC5123C-R3

    High-Density Media Converter System II Layer 2 Module, 100BASE-TX to 100BASE-FX, Single Strand, Single-Mode, 1310-nm-TX/1550-nm RX, SC, 20 Km

    High-Density Media Converter System II Layer 2 Module, 100BASE-TX to 100BASE-FX, Single Strand, Single-Mode, 1310-nm-TX/1550-nm RX, SC, 20 km

    » more info
