Networking > Wireless

click photo to enlarge

LS900A-R2

Photo may show similar product

Other views

LongSpan Wireless Ethernet Extender, Indoor/Outdoor Radio

The core of the LongSpan system.

LS900A-R2

Extended Double Diamond™ Warranty Available
(3 Additional Year)

Product Highlights

  • Extends Ethernet wirelessly over very long distances—up to 40 miles (line-of-sight).
  • Superior penetration through walls and foliage.
  • 900-MHz bandwidth requires no FCC license and won't interfere with Wi-Fi®.
  • NEMA 4x rated for indoor or outdoor use.
  • Powered through PoE or AC power adapter for convenient installation.

  • Description

    LongSpan Wireless Ethernet Extender, Indoor/Outdoor Radio


    Quick Facts

  • Extends Ethernet wirelessly over very long distances—up to 40 miles (line-of-sight).
  • Superior penetration through walls and foliage.
  • 900-MHz bandwidth requires no FCC license and won't interfere with Wi-Fi®.
  • NEMA 4x rated for indoor or outdoor use.
  • Powered through PoE or AC power adapter for convenient installation.

  • Further Details

    LongSpan 900-MHz Wireless Ethernet Extenders provide a great way to extend an Ethernet network where installing cable is impractical or prohibitively expensive, and Wi-Fi is ineffective.

    Because LongSpan covers very long distances, it can provide a link where ordinary 802.11a/b/g wireless can't go. Outdoors, it has a range of up to 40 miles line of sight or up to 1500 feet through trees. Indoors, it will penetrate up to 10 building walls.

    LongSpan is ideal for a wide range of applications such as:
  • Providing links to far-flung security cameras or door-access controls.
  • Linking to VoIP phones in remote locations such as security stations.
  • Linking interbuilding networks in a very large installation or in a rural setting such as a park.
  • Linking to distant sensors and controls, such as a weather station.
  • Extending the reach of an 802.11 wireless network across a large facility such as an airport or a military base.


  • Indoor/Outdoor Radio
    This tough 900-MHz radio is the core of the LongSpan system. Use it with just the included antenna or add an antenna for increased range. You can buy the Indoor/Outdoor Radio separately or as a part of the Integrated Radio and Directional Antenna (LS900PKA) or one of our LongSpan Surveillance Solutions. The LongSpan Indoor/Outdoor Radio works in point-to-point, multipoint, or broadcast applications.

    Power the radio through the Ethernet cable using Power over Ethernet (PoE) or with the included AC power adapter.

    The radio is IP addressable; the convenient Web browser interface enables you to manage and control the radio through your network. Use your Web browser to access the built-in spectrum analyzer to view signal strength and monitor radio channel activity. And, of course, the radio features 128-bit AES encryption to keep out unwanted snoops.

    The LongSpan Indoor/Outdoor Radio is NEMA 4x rated for indoor or outdoor use. It provides protection against falling dirt, rain, sleet, snow, windblown dust, splashing water, and hose-directed water. The unit is corrosion resistant and is unharmed by ice on the outside of the enclosure. It operates in a wide temperature range of -40° to +158° F. A built-in lightning arrestor guards against outages caused by nearby lightning strikes (of course, nothing can protect against a direct lightning strike).



    This product works with:
  • LongSpan Antennas (LS900-15Y, 5M)
  • LongSpan Security-Camera Kits (LS900-DOME-KIT, TUBE-KIT)
  • Questions? Contact our FREE Tech Support.

    What's included:
  • (1) radio with (1) 2.5-dBi omnidirectional antenna
  • (1) power supply
  • (1) PoE mid-span power injector
  • (1) pole-mount bracket

  • Technical Specifications for LongSpan Wireless Ethernet Extender, Indoor/Outdoor Radio :

    Distance 40 miles line of sight with 15-dBi antenna
    Environmental Operating temperature: -40 to +158° F (-40 to +70° C)
    Radio Channels/Bandwidth 12 non-overlapping with 2.0833-MHz spacing and 1.75-MHz occupied bandwidth
    Radio Link Budget 148 dB with 15 dBi antenna
    Receive Sensitivity -97 dBm at 10e-4 BER (-112 dBm with 15-dBi antenna)
    Speed RF Transmission Rate: 1.536 Mbps;
    Ethernet Throughput: 935 kbps
    Connectors (1) RJ-45 PoE 10BASE-T/100BASE-TX
    Indicators LEDs: (1) Power, (1) Ethernet Link, (1) RF RX, (1) RF TX, (4) Channel, (6) Link Quality
    Power From 110-VAC, 60 Hz external power adapter or PoE injector
    Size 2"H x 6.7"W x 3.1"D (5 x 17 x 8 cm)

    This product works with:
  • LongSpan Antennas (LS900-15Y, 5M)
  • LongSpan Security-Camera Kits (LS900-DOME-KIT, TUBE-KIT)
  • Questions? Contact our FREE Tech Support.

    What's included:
  • (1) radio with (1) 2.5-dBi omnidirectional antenna
  • (1) power supply
  • (1) PoE mid-span power injector
  • (1) pole-mount bracket


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.

  • Resources for LongSpan Wireless Ethernet Extender, Indoor/Outdoor Radio :

    Manuals

    • LongSpan Wireless Ethernet Extender, Indoor/Outdoor Radio, User Manual
      User Manual for the LS900A-R2 (Version 1)


    Connect your LongSpan Wireless Ethernet Extender, Indoor/Outdoor Radio with:

    Accessory: LS900-15Y

    LongSpan Wireless Ethernet Extender, Long-Distance 900-MHz Directional 15-dBi Yagi Antenna

    LongSpan Wireless Ethernet Extender, Long-Distance 900-MHz Directional 15-dBi Yagi Antenna

    Accessory: LS900-5M

    LongSpan Wireless Ethernet Extender, Medium-Range 900-MHz Omnidirectional 5-dBi Antenna

    LongSpan Wireless Ethernet Extender, Medium-Range 900-MHz Omnidirectional 5-dBi Antenna
