Premises Security > Biometrics

click photo to enlarge

SAC550CAB

Photo may show similar product

Other views

Intelli-Pass Biometric Access Control for Cabinets, with Battery Backup

The cabinet lock that’s highly secure, yet opens at the touch of a fingertip.

SAC550CAB

Extended Double Diamond™ Warranty Available
(Three years for two)

Product Highlights

  • Eliminates keys that can be lost, stolen, or duplicated; no need to remember combinations.
  • The lock opens only when an authorized user touches the fingerprint scanner—one fingertip provides cabinet access.
  • LEDs on front of the handle monitor status.
  • Manageable across your network as part of the Intelli-Pass biometric access control system.

  • Description

    Intelli-Pass Biometric Access Control for Cabinets, with Battery Backup


    Quick Facts

  • Eliminates keys that can be lost, stolen, or duplicated; no need to remember combinations.
  • The lock opens only when an authorized user touches the fingerprint scanner—one fingertip provides cabinet access.
  • LEDs on front of the handle monitor status.
  • Manageable across your network as part of the Intelli-Pass biometric access control system.

  • Further Details

  • Continues to operate normally even if your network fails—network communication isn’t required for fingerprint verification.
  • Controller unit and optional backup battery are housed in a compact 1U rackmount chassis.

  • The Intelli-Pass™ Biometric Access Control for Cabinets provides the perfect blend of security and simplicity—the touch of one fingertip gives authorized users access. One control unit unlocks the front door and—with the purchase of an additional door handle—the rear door.

    Secure two-part architecture
    The Intelli-Pass cabinet lock features the same unique two-part architecture as the rest of the Intell-Pass family. A reader unit mounts outside the cabinet on the locking handle, and a controller unit is rackmounted inside the cabinet. Because the reader and controller units are separate, no connections in the reader unit are exposed to the outside. The controller is secure inside the cabinet, and a hacker can’t cut wires or spoof the signals to open the door.

    Secure locking
    Electric strike locks can be set to provide fail-safe or fail-secure door lock operation. A fail-safe lock requires power to keep it locked. A fail-secure lock stays locked even without power but requires power to open it.

    The Intelli-Pass system in each cabinet operates independently, so if the network fails, your cabinet locks will not.

    If you’re using Intelli-Pass in a cabinet without a UPS for backup power, this Intelli-Pass model model offers the battery backup that ensures flawless operation even if power fails.

    Integrates seamlessly into your Intelli-Pass system
    Intelli-Pass Biometric Access Control for Cabinets works as part of a complete Intelli-Pass solution. Intelli-Pass Management and Enrollment Software audits when someone accesses the cabinet using their biometric fingerprint. The software monitors real-time status information, provides an access trail, and enables you to handle all the enrollment and management of the secure cabinets from a single desktop.

    Alarming
    Intelli-Pass can work with your building’s alarm system to automatically open cabinets when the alarm goes off, allowing emergency access to critical equipment. The door handle is also equipped with a keyed lock for emergency access. Plus you can connect the controller to door sensors, enabling the system to alert you if a door is opened.

    Order with your cabinet or install it later
    Intelli-Pass Biometric Access Control works with our Elite™ Cabinets as well as many other standard server cabinets. You may also specify Intelli-Pass Biometric Access Control as a lock option when you order an Elite Cabinet. For more information, call our FREE Tech Support at 724-746-5500.


    What’s included:
  • Fingerprint sensor unit
  • Door handle with integrated lock
  • 1U rackmount chassis containing control unit and optional battery
  • Power cord
  • (2) patch cables
  • (2) keys

  • This product works with:
  • Elite™ Cabinets
  • Door Handle with Integrated Lock (SAC550CABL)
  • Security Sensor (SAC550CABS)
  • Standard server cabinets
  • Questions? Contact our FREE Tech Support.


    Technical Specifications for Intelli-Pass Biometric Access Control for Cabinets, with Battery Backup:

    Environmental — Operating Temperature: 32 to 158° F (0 to 70° C)
    Connectors — Chassis:
    (1) RJ-45 network,
    (1) RJ-45 front door,
    (1) RJ-45 rear door,
    (1) 6-position terminal block,
    (1) 12-position terminal block
    Power — Internal power supply: 100–240-VAC, 50/60 Hz, 3.5 amps
    Size — Chassis: 1.75"(1U) H x 19"W x 8"D (4.4 x 48.3 x 20.2 cm);
    Door handle: Fits 1" x 5.9" (2.5 x 15 cm) opening
    Weight — 12 lb. (5.4 kg)
    This product works with:
  • Elite™ Cabinets
  • Door Handle with Integrated Lock (SAC550CABL)
  • Security Sensor (SAC550CABS)
  • Standard server cabinets
  • Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for Intelli-Pass Biometric Access Control for Cabinets, with Battery Backup:

    Manuals

    • Intelli-Pass Biometric Access Control for Cabinets Manual
      Manual for the SAC550CAB, SAC550CABNB, SAC550CABL, and SAC550CABS.

    Product Data Sheets


    Connect your Intelli-Pass Biometric Access Control for Cabinets, with Battery Backup with:

    Accessory: EC45U2436SPMSMNK

    Elite Server Cabinet, 84"H (45U) x 24"W x 36"D, M6 Rails, PLEXIGLAS® Front Door, Mesh Rear Door, Solid Side Panels, Mesh Top Panel, Keyed Locks

    Elite Server Cabinet, 84"H (45U) x 24"W x 36"D, M6 Rails, PLEXIGLAS® Front Door, Mesh Rear Door, Solid Side Panels, Mesh Top Panel, Keyed Locks

    Accessory: SAC550CABL

    Door Handle with Electronic Lock, for Use with Intelli-Pass Cabinet Lock

    Door Handle with Electronic Lock, for Use with Intelli-Pass Cabinet Lock

    Accessory: SAC550CABS

    Intelli-Pass Biometric Access Control for Cabinets, Security Sensor

    Intelli-Pass Biometric Access Control for Cabinets, Security Sensor

    Double Diamond Warranty

    Standard Manufacturer's Warranty


    A One year warranty is included.

    Extended Two years for one Warranty Available


    Protect your purchase with an additional Two years for oneDouble Diamond™ warranty!
    Cost: $189.50

    Extended Three years for two Warranty Available


    Protect your purchase with an additional Three years for twoDouble Diamond™ warranty!
    Cost: $379.00

    Diamond

    Double Diamond™ Warranty (Standard)

    Coverage:

    The most complete product warranty exclusively from Black Box

    The Double Diamond™ Warranty is our no-questions-asked warranty that protects your Black Box® brand products* from accidental damage, including drops, water, and power surges.

    Most products come with a one- or two-year warranty. Some products, such as copper cables, manual switches, cabinets, and racks, are guaranteed for life! Standard Warranty features are as follows:

    Worry-Free Purchases

    If your new Black Box® brand products are accidentally damaged, you're covered with this no-questions asked warranty. FREE

    Coverage

    Double Diamond™ is the standard warranty that comes with your new Black Box® brand product. Most products come with a one- or two-year warranty.

    Lifetime Guarantees

    Many products, such as copper cables, manual switches, cabinets, and racks, are guaranteed for life.

    Fast Service

    During the warranty period, Black Box® Network Services will repair or replace your damaged equipment within one week of receipt at NO CHARGE!

    Extra Coverage

    Extend your warranty or protect a previously purchased Black Box® brand product* for an additional year for only 10% of the current retail price! And when you do, we give you the second year of extended coverage free! FREE Tech Support Hotline. No cost. No contracts. No kidding!

    No-Risk 45-Day Return Policy

    If it's not right, send it back.
    (Excludes custom built products)

    * Certain products may not be eligible.

    Warranty Compared

    Black Box® Double Diamond™ Warranty The Competition
    Warranty Length One Year to Lifetime, Depending on the Product. Read the fine print.
    Guaranteed for Life! Black Box® Brand Copper Cables, Manual Switches and More! No.
    Accidental Damage 100% Covered! No.
    Water Damage 100% Covered! No.
    Power Surges 100% Covered! No.
    Warranty Replacements No Questions Asked! Forget It.
    Tech Support Hotline 100% FREE! $$$
