ICD111A

Photo may show similar product

Other views

Industrial USB 2.0 to Dual-Port RS-232 DIN Rail Converter

Connect your USB 2.0 computer to RS-232 commercial and industrial equipment!

ICD111A

Extended Double Diamond™ Warranty Available
(3 Additional Year)

Product Highlights

  • Use your new computer with older workhorse devices.
  • Provide 3000-VDC optical isolation between ports.
  • RoHS compliant.
  • Powered from the USB interface.
  • Automatic configuration on Windows® 98/Me/XP, Windows 2000, and Windows Vista™.


  • Description

    Industrial USB 2.0 to Dual-Port RS-232 DIN Rail Converter


    Quick Facts

  • Use your new computer with older workhorse devices.
  • Provide 3000-VDC optical isolation between ports.
  • RoHS compliant.
  • Powered from the USB interface.
  • Automatic configuration on Windows® 98/Me/XP, Windows 2000, and Windows Vista™.

  • Further Details

  • Mount to a DIN rail.
  • LEDs indicate transmit and receive data.
  • Include 1-meter (3.2-ft.) USB cable.
  • Perfect for point-of-sale, medical, SCADA, and factory-automation applications.

    USB 2.0↔Single- and Dual-Port RS-232 DIN Rail Converters
  • Increase your PC's capability by adding one or two COM ports.
  • Provide 15-kV ESD surge protection against spikes and ground loops.
  • Data rates up to 12 Mbps for USB and 460.8 kbps for RS-232.
  • Use all RS-232 handshaking.

  • USB 2.0↔Single- and Dual-Port RS-422/RS-485 DIN Rail Converters
  • Increase your PC's capability by adding one or two COM ports.
  • Include one or two pluggable terminal blocks.
  • Use on 2-wire RS-485 or 4-wire RS-422/RS-485 networks.
  • Data rates up to 12 Mbps for USB and 921.6 kbps for RS-422/RS-485.
  • Support Send Data Control, TDA, TDB, RDA, RDB, and GND.


  • Technical Specifications for Industrial USB 2.0 to Dual-Port RS-232 DIN Rail Converter :

    Isolation and Surge Protection Isolation: 3000-VDC optical isolation between ports;
    ICD110A-ICD111A also provide 15-kV ESD surge protection
    MTBF 118,048 hours
    Operating Systems Supported Windows® 98/Me/XP, Windows 2000, and Windows Vista™
    Operating Temperature 32 to 158° F (0 to 70° C)
    Speed (Maximum) USB: 12 Mbps;
    RS-232: ICD110A-ICD111A: 460.8 kbps;
    RS-422/RS-485: ICD112A-ICD113A: 921.6 kbps
    CE Approval Yes
    Connectors All: (1) USB Type B F;
    ICD110A-ICD111A: RS-232: (1) or (2) DB9 M;
    ICD112A-ICD113A: RS-422/RS-485: (1) or (2) pluggable terminal blocks
    Power From the USB interface
    Dimensions 4.9"H x 1.6"W x 3.3"D (12.4 x 4.1 x 8.4 cm)

    These products work with:
  • DB9 Male/Female Cable (BC00200, etc.)
  • Individually Shielded Low-Capacitance Cable–Extra Distance (ERN04A, etc.)
  • DIN Rail (DR100)
  • Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.
