LIC022A-R2

Photo may show similar product

Other views

Industrial MultiPower Media Converter, 10-/100-Mbps Copper to 100-Mbps Duplex Fiber, Multimode 1300-nm, 2 km, ST

Choose from five different ways to power this hardened media converter.

LIC022A-R2

Extended Double Diamond™ Warranty Available
(3 Additional Year)

Product Highlights

  • Five ways to power: universal AC power supply, DC terminal block, a PC's USB port, 802.3af Power over Ethernet (PoE), or the optional rackmountable PowerTray.
  • Convert 10-/100-Mbps copper to duplex 100-Mbps fiber, autonegotiating for speed on the copper side.

  • Description

    Industrial MultiPower Media Converter, 10-/100-Mbps Copper to 100-Mbps Duplex Fiber, Multimode 1300-nm, 2 km, ST


    Quick Facts

  • Five ways to power: universal AC power supply, DC terminal block, a PC's USB port, 802.3af Power over Ethernet (PoE), or the optional rackmountable PowerTray.
  • Convert 10-/100-Mbps copper to duplex 100-Mbps fiber, autonegotiating for speed on the copper side.

  • Further Details

  • Extended temperature range when used with DC power: -13 to +158º F (-25 to +70° C).
  • Includes clips for mounting on DIN rails.

  • This ultra-compact, plug-and-play converter offers multiple power options, including support for the IEEE 802.3af Power over Ethernet (PoE) standard. Plus, the Industrial MultiPower Media Converter is designed for use in harsh industrial environments.

    For extra versatility, you can power the Industrial MultiPower Media Converter through the external AC power supply included with each converter, using 5–50-VDC terminal block power, through 802.3af Power over Ethernet (PoE), through the optional USB Power Adapter Cable (LHC021A), which plugs into a PC's USB port, or through the optional rackmount PowerTray (LHC018A-AC-R2).

    You can even use multiple power options at the same time to provide maximum redundancy and ensure that your mission-critical applications remain up and running. For instance, you can connect a converter to power sourcing equipment (PSE) for PoE while also using AC adapter power, DC terminal block power, and USB bus power. Then, if any one of these power sources fails, the other sources will continue to supply power to the converter seamlessly.

    You can also connect a PSE switch to an uninterruptible power supply to ensure that the switch and each connected media converter always have power.

    The converter comes with DIN clips, so you can attach it to a DIN rail. When installing multiple Industrial MultiPower Media Converters on a DIN rail, use one DC input source, then cascade from one DC block to the next until you reach the maximum current available.
    NOTE: The included AC power adapter doesn't work with the earlier version of this converter (LIC022A).

    This product works with:
  • USB Power Adapter Cable (LHC021A)
  • PowerTray (LHC018A-AC-R2)
  • Questions? Contact our FREE Tech Support.


    Technical Specifications for Industrial MultiPower Media Converter, 10-/100-Mbps Copper to 100-Mbps Duplex Fiber, Multimode 1300-nm, 2 km, ST:

    Cable Requirements Twisted pair: CAT5 or above, shielded or unshielded;
    Multimode fiber: 50-/125-µm or 62.5-/125-µm duplex
    Operating Environment Temperature: Using AC adapter: +32 to +122° F (0 to +50° C);
    Using other available power sources: -13 to +158° F (-25 to +70° C);
    Humidity: 5 to 95% noncondensing
    Switching Engine Store-and-forward; autonegotiating; broadcast storm protection; supports oversized packets up to 1916 bytes
    CE Approval Yes
    Connectors (1) RJ-45, with autocross for MDI-II/MDI-X;
    (1) pair of ST
    Indicators LEDs: (1) FX LNK/ACT, (1) TX LNK/ACT
    Power From the included external 100-240-VAC, 50-60-Hz adapter;
    Via the terminal block: 5 to 50 VDC;
    Via USB Power Adapter Cable (LHC021A) connected to a computer's USB port;
    From the PowerTray with a 100-240 VAC, 50-60 Hz (LHC018A-AC-R2) power supply
    From a PSE over a Power over Ethernet link
    Size 0.8"H x 1.8"W x 3.4"D (2 x 4.6 x 8.6 cm)

    NOTE: The included AC power adapter doesn't work with the earlier version of this converter (LIC022A).

    This product works with:
  • USB Power Adapter Cable (LHC021A)
  • PowerTray (LHC018A-AC-R2)
  • Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.
