DS3TNC-0010

Photo may show similar product

Other views

High-Speed DS-3 Coax Cable, TNC-TNC, 10-ft. (3.0-m)

The right connection for your high-speed DS-3 equipment.

DS3TNC-0010

Extended Double Diamond™ Warranty Available
(Lifetime)

Product Highlights

  • Use to interconnect or cross-connect DS-3 transmission equipment and Digital System Cross-connect (DSX) systems.
  • Guaranteed for life!


  • Description

    High-Speed DS-3 Coax Cable, TNC-TNC, 10-ft. (3.0-m)


    Quick Facts

  • Use to interconnect or cross-connect DS-3 transmission equipment and Digital System Cross-connect (DSX) systems.
  • Guaranteed for life!

  • Further Details

  • Cable is Siamese-style with two conductors.
  • For superior performance, conductors are solid, silver-plated, 26 AWG copper.
  • Low attenuation at standard frequencies.
  • For indoor environments.
  • UL® listed to NEC® and CEC Type CMR.
  • Compliant with Bellcore GR-139-CORE specifications and flame resistant to UL® 1666.
  • Available with TNC connectors also.
  • Other lengths are available.


  • Technical Specifications for High-Speed DS-3 Coax Cable, TNC-TNC, 10-ft. (3.0-m):

    Impedance (Nominal) 75 ohms
    Conductors 26 AWG silver-plated, solid copper
    Construction 95% coverage braid
    CSA CXC FT-4
    Dielectric Cellular polyethylene
    Jacket Gray PVC
    Rating UL® Listed, NEC® Type CMR
    Return Loss 30 dB at 100 MHz minimum
    Shield Foil with tinned copper
    Structural Loss 30 dB at 15-90 MHz
    Velocity of Propagation (Nominal) 78%


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for High-Speed DS-3 Coax Cable, TNC-TNC, 10-ft. (3.0-m):


    Connect your High-Speed DS-3 Coax Cable, TNC-TNC, 10-ft. (3.0-m) with:

    Double Diamond Warranty

    Extended LIFETIME Warranty Available


    Protect your purchase with an additional LIFETIME Double Diamond™ warranty!
    Cost: $0.00

    Diamond

    Double Diamond™ Warranty (Standard)

    Coverage:

    Take the risk out of equipment purchases with the Double Diamond™ Warranty from Black Box Network Services.


    The Double Diamond Warranty is our warranty that protects your Black Box® brand products* from accidental damage, including drops, water, and power surges.

    The High-Speed DS-3 Coax Cable, TNC-TNC, 10-ft. (3.0-m) comes with a standard Lifetime warranty already included.

    During the warranty period, Black Box Network Services will repair or replace your damaged equipment within one week of receipt at NO CHARGE!*

    Plus, get an Extended Double Diamond Warranty.


    You can also extend your warranty or protect a previously purchased Black Box® brand product** for an additional year—for only 10% of the purchase price! Or, extend your coverage for a full three years for only 20% of the purchase price!

    Ordering an extended warranty is easy: When viewing a product in your shopping cart, just select the one or three years of additional coverage in the dropdown menu under “Warranty Options.” For details, contact Customer Service at 724-746-5500.

    * Warranty subject to certain exclusions and limitations
    ** Certain products may not be eligible.

    What’s more, we also have a 45-day return policy. Simply call Customer Service for a Return Authorization (RA) number, return your product in new condition and in the original package, and receive a full refund.

    Product SKU Price Quantity
    High-Speed DS-3 Coax Cable, BNC-BNC, 2-ft. (0.6 m) DS3-0002-BNC $31.95

    High-Speed DS-3 Coax Cable, BNC-BNC, 5-ft. (1.5 m) DS3-0005-BNC $35.95

    High-Speed DS-3 Coax Cable, BNC-BNC, 10-ft. (3.0-m) DS3-0010-BNC $40.95

    High-Speed DS-3 Coax Cable, BNC-BNC, 25-ft. (7.6-m) DS3-0025-BNC $50.95

    High-Speed DS-3 Coax Cable, BNC-BNC, 50-ft. (15.2-m) DS3-0050-BNC $60.95

    High-Speed DS-3 Coax Cable, BNC-BNC, 100-ft. (30.4-m) DS3-0100-BNC $80.95

    High-Speed DS3 Coax Cable, BNC–BNC, Custom Lengths DS3BNC $69.46
    High-Speed DS-3 Coax Cable, TNC-TNC, Custom Lengths DS3TNC $100.36
    High-Speed DS-3 Coax Cable, TNC-TNC, 25-ft. (7.6-m) DS3TNC-0025 $133.95

    High-Speed DS-3 Coax Cable, TNC-TNC, 50-ft. (15.2-m) DS3TNC-0050 $171.95

    You can find this product in the following subcategory(s)


    Add to Cart

    Price: $109.95

    Quantity Available: 3

    Quantity

    Warranty

    Total

    Shipping Info

    In Stock - orders received before 5PM ET ship same day

    Weight: 0.375 lbs.
    HxWxD: 0.75 x 8.25 x 8.75 in.
