Networking > Media Converters

click photo to enlarge

LMC5028C

Photo may show similar product

Other views

High-Density Media Converter System II Fiber Mode Conversion/Repeater Module, 155 Mbps (Fast Ethernet), Multimode, 1300-nm to Single-Mode, 1310-nm, 2 km Multimode/40 km Single-Mode, ST/ST

Add extra distance to your network—convert multimode to single-mode at 10/100- or OC-3 ATM speeds.

LMC5028C

Extended Double Diamond™ Warranty Available
(Three years for two)

Product Highlights

  • Protocol-independent conversion from multimode to single-mode fiber.
  • Works with High-Density Media Converter System II Chassis.
  • Supports 155-Mbps Fast Ethernet and OC-3 ATM applications.

  • Description

    High-Density Media Converter System II Fiber Mode Conversion/Repeater Module, 155 Mbps (Fast Ethernet), Multimode, 1300-nm to Single-Mode, 1310-nm, 2 km Multimode/40 km Single-Mode, ST/ST


    Quick Facts

  • Protocol-independent conversion from multimode to single-mode fiber.
  • Works with High-Density Media Converter System II Chassis.
  • Supports 155-Mbps Fast Ethernet and OC-3 ATM applications.

  • Further Details

    High-Density Media Converter System II, Fiber Mode-Conversion/Repeater Module, 155-Mbps belongs to a large family of modular media converter and communications options that provide an exceptional range of choices for your managed enterprise network. The High-Density Media Converter System II is particularly well suited for network-extension applications, offering a wide range of hot-swappable converter modules for network extension over fiber. The system offers a range of modules that are not usually available with chassis-based media converter systems.

    This system can adapt to even the most demanding network configurations. All converter modules are hot-swappable—you never need to power down a chassis to change a module.

    The module featured here is a protocol-independent fiber mode-conversion/repeater module that converts multimode to single-mode fiber. Use it to add extra distance—up to 80 kilometers (49.7 mi.)—to your fiber infrastructure. Or use it for migrating from a multimode fiber infrastructure to single-mode one.

    Supporting up to 155 Mbps, it’s typically used for Ethernet or Fast Ethernet. But because it’s transparent to protocol, it can also be used in an OC-3 ATM (155-Mbps) environment.

    Includes FiberAlert™ to notify you of “silent failures” and help you troubleshoot problems. No more time wasted searching for it! You can check a link by observing the status of the mode converter’s Link LED.

    The FiberAlert function informs you when a fault occurs on one fiber strand and the link can’t carry bidirectional communications between two fiber devices. With FiberAlert, the link status of one end is mirrored at the opposite end. If a strand isn’t available, and you have FiberAlert enabled, the receiver end device notes the loss of the link and stops transmitting data until it receives a signal or link pulse. This means that the link status can be seen at both ends through the respective Link LEDs, thus helping you to identify and isolate faults anywhere in the fiber loop. FiberAlert works even if the fiber devices are separated by great distances.


    Technical Specifications for High-Density Media Converter System II Fiber Mode Conversion/Repeater Module, 155 Mbps (Fast Ethernet), Multimode, 1300-nm to Single-Mode, 1310-nm, 2 km Multimode/40 km Single-Mode, ST/ST:


    This product works with:
  • High-Density Media Converter System II Chassis
  • Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for High-Density Media Converter System II Fiber Mode Conversion/Repeater Module, 155 Mbps (Fast Ethernet), Multimode, 1300-nm to Single-Mode, 1310-nm, 2 km Multimode/40 km Single-Mode, ST/ST:


    Connect your High-Density Media Converter System II Fiber Mode Conversion/Repeater Module, 155 Mbps (Fast Ethernet), Multimode, 1300-nm to Single-Mode, 1310-nm, 2 km Multimode/40 km Single-Mode, ST/ST with:
