Networking > Media Converters

click photo to enlarge

LMC5203A

Photo may show similar product

Other views

High-Density Media Converter System II Chassis, Managed, 6-Slot Desktop/Rackmount, AC Power

Use this compact 6-slot chassis for media converter modules. Then add an SNMP module for management.

LMC5203A

Extended Double Diamond™ Warranty Available
(Three years for two)

Product Highlights

  • Fully manageable with full platform control when used with the SNMP Management Module.
  • Compatible with a number of modules: copper-to-fiber, fiber-to-fiber, single-strand, VDSL, and others!

  • Description

    High-Density Media Converter System II Chassis, Managed, 6-Slot Desktop/Rackmount, AC Power


    Quick Facts

  • Fully manageable with full platform control when used with the SNMP Management Module.
  • Compatible with a number of modules: copper-to-fiber, fiber-to-fiber, single-strand, VDSL, and others!

  • Further Details

  • Thermostatically-controlled cooling fans keep chassis from becoming overheated and causing downtime.
  • We also offer other managed models: a 3-slot desktop chassis and a 20-slot 3U-high rackmount chassis.
  • For unmanaged remote office links, order compact 1-slot or 2-slot desktop chassis models.

  • This Black Box® 6-Slot High-Density Media Converter System II Chassis makes it easy to consolidate multiple media converters in a single platform at a central point in your application.

    Add the SNMP Management Module for full chassis and module control.
    This chassis becomes fully manageable with the optional SNMP Management Module. It features a 10BASE-T/100BASE-TX twisted-pair port for connection to your LAN and is used in the chassis to enable both module and chassis management. Once connected to your network, a chassis can even be assigned its own IP address.

    The software included with the SNMP Management Module enables you to configure and manage your chassis and its connections. Through the user-friendly IView® interface, you can manage the chassis’ modules and any intelligent networking devices on virtually any 32-bit Windows® system. The GUI features device control panels, gives you detailed conversion port information, presents statistical information as charts, and more!

    And because the management module includes SNMP MIBs for support of industry-standard SNMP, you can monitor chassis temperature and voltage levels, diagnose network problems, and set up SNMP traps to alert you to potential network failures to lessen any potential downtime.

    You can even set a SNMP write-lock switch to protect the configurations of your installed modules from being accidentally overwritten.

    For out-of-band management, connect a console to the SNMP module’s RS-232 port. The managed system uses DCHP, includes a TFTP client, and supports Telnet.

    To keep your chassis running in mission-critical applications, order redundant AC or DC power supplies.

    Order unmanaged chassis for remote sites.
    We also offer compact desktop chassis models that you can use as remote units that communicate with the larger High-Density Media Converter System II Chassis located at a central office.

    Available with 1- or 2 slots, the desktop chassis can also be used in pairs if you don’t require any SNMP management capabilities in your application.

    The 1-slot models hold one module and are powered by either an autosensing 115–240-VAC power supply or a combination AC/DC power supply that supports operation in environments with extremes in temperature. The AC/DC model also has a clip for mounting it on a DIN rail.

    The 2-slot models feature a small footprint, house two converter modules, and come with an AC or a DC power supply.

    To save desktop space, use the optional brackets to mount your chassis in a rack or on a wall. You can also order a Rackmount Shelf, which enables you to install up to three unmanaged chassis in a standard rack.

    For assistance specifying your complete High-Density Media Converter System II, contact our FREE Tech Support.

    This product works with:
  • SNMP Management Module (LMC5200A)
  • High-Density Media Converter System II Layer 1 Modules
  • High-Density Media Converter System II Layer 2 Modules
  • High-Density Media Converter System II Fiber Mode Conversion/Repeater Modules
  • High-Density Media Converter System II VDSL Modules
  • High-Density Media Converter System II T1/E1/J1 Modules
  • High-Density Media Converter System II DS3/E3/STS-1 Modules
  • High-Density Media Converter System II Bandwidth Manager (LE1028C)
  • CAT5 100-MHz Solid-Conductor Cable, 4-Pair, Straight-Pinned (EYN737MS)
  • Questions? Contact our FREE Tech Support.


    Technical Specifications for High-Density Media Converter System II Chassis, Managed, 6-Slot Desktop/Rackmount, AC Power:

    Approvals — FCC Class B, Part 15
    Environmental — Operating Temperature: +32 to +122° F (0 to +50° C);
    Storage Temperature: -13 to +158° F (-25 to +70° C);
    Humidity: 5 to 95% (noncondensing)
    CE Approval — Yes
    Indicators — LNK, FDX, RCV, XMT, MGMT, SNMP
    Power — 100–240 VAC, 50/60 Hz, autosensing, 1/0.5 A
    Size — 1.75" (1U) H x 17.35"W x 13.8"D (4.4 x 44.1 x 35.1 cm)
    Weight —5 lb. (2.3 kg)
    NOTE: For assistance specifying your complete High-Density Media Converter System II, contact our FREE Tech Support.

    This product works with:
  • SNMP Management Module (LMC5200A)
  • High-Density Media Converter System II Layer 1 Modules
  • High-Density Media Converter System II Layer 2 Modules
  • High-Density Media Converter System II Fiber Mode Conversion/Repeater Modules
  • High-Density Media Converter System II VDSL Modules
  • High-Density Media Converter System II T1/E1/J1 Modules
  • High-Density Media Converter System II DS3/E3/STS-1 Modules
  • High-Density Media Converter System II Bandwidth Manager (LE1028C)
  • CAT5 100-MHz Solid-Conductor Cable, 4-Pair, Straight-Pinned (EYN737MS)
  • Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for High-Density Media Converter System II Chassis, Managed, 6-Slot Desktop/Rackmount, AC Power:

    Product Data Sheets

    Firmware

    • Media Converters/High-Density Media Converter System II Firmware
      Firmware for LMC5200, LMC5228A, LMC5208A-R2, LMC5207A-R2, LMC5227A, LMC5205A, LMC5206A, LMC5204A, LMC5203A, LMC5237A, LMC5236A, LMC5235A, LMC5234A, and LMC5233A (1)

    Black Box Explains


    Connect your High-Density Media Converter System II Chassis, Managed, 6-Slot Desktop/Rackmount, AC Power with:

    Accessory: LGC5950C-R2

    High-Density Media Converter System II Layer 2 Module, 10BASE-T/100BASE-TX/1000BASE-T to 1000BASE-SX, Multimode, 850-nm, 220 m, SC

    High-Density Media Converter System II Layer 2 Module, 10BASE-T/100BASE-TX/1000BASE-T to 1000BASE-SX, Multimode, 850-nm, 220 m, SC

    Accessory: LME020A

    High-Density Media Converter System II DS3/E3/STS-1 to Duplex Fiber Modules, ST

    High-Density Media Converter System II DS3/E3/STS-1 to Duplex Fiber Module, BNC to MM 1300-nm, 2 km, ST

    Accessory: LGC5951C-R2

    High Density Media Converter System II Layer 2 Module, 10BASE-T/100BASE-TX/1000BASE-T to 1000BASE-LX, Single-Mode, 1310-nm, 15 km, SC

    High Density Media Converter System II Layer 2 Module, 10BASE-T/100BASE-TX/1000BASE-T to 1000BASE-LX, Single-Mode, 1310-nm, 15 km, SC

    Accessory: LMC5200A

    High-Density Media Converter System II SNMP Management Module , SNMP Management Module

    SNMP Management Module for High-Density Media Converter System II Chassis

    Accessory: LMC5118C-R3

    High-Density Media Converter System II, Layer 2 Module, 10BASE-T/100BASE-TX to 10BASE-FX, Multimode, 1300-nm, ST, 2 km

    High-Density Media Converter System II, Layer 2 Module, 10BASE-T/100BASE-TX to 10BASE-FX, Multimode, 1300-nm, ST, 2 km

    Accessory: LMC5036C

    High-Density Media Converter System II Fiber Mode-Conversion Modules, 1250 Mbps (OC-12 ATM)

    High-Density Media Converter System II, Fiber Mode Conversion/Repeater Modules, 1250 Mbps (OC-12 ATM), Multimode, 850-nm to Single-Mode, 1310-nm, 2 km Multimode/10 km Single-Mode, SC/SC

    Accessory: LMC5014C-R2

    High-Density Media Converter System II, Layer 1 Module, 10BASE-T to 10BASE-FL, Multimode, 850-nm, 4 km, ST

    High-Density Media Converter System II, Layer 1 Module, 10BASE-T to 10BASE-FL, Multimode, 850-nm, 4 km, ST

    Accessory: LME001A

    High-Density Media Converter System II T1/E1/J1 to Duplex Fiber Module, Twisted Pair (RJ-48) to Multimode, 1300-nm, 2 km, ST

    High-Density Media Converter System II T1/E1/J1 to Duplex Fiber Module, Twisted Pair (RJ-48) to Multimode, 1300-nm, 2 km, ST

    Accessory: LMC5214A

    High-Density Media Converter System II AC Module for LMC5203A, AC Module for LMC5203A

    AC Module for LMC5203A High-Density Media Converter System II Chassis
