Datacom > Converters

click photo to enlarge

MT256A-F

Photo may show similar product

Other views

G.703 75–120 Adapter, Female with 1.6/5.6 Coax Connectors and Transformer Isolation, 2.048-Mbps

Use twisted-pair equipment with your G.703 network.

MT256A-F

Extended Double Diamond™ Warranty Available
(Three years for two)

Product Highlights

  • Solve mismatches between coax and twisted-pair equipment.
  • Make 75-ohm (dual-coax) and 120-ohm (twisted-pair) network connections.
  • Convert bidirectionally between G.703 balanced and unbalanced interfaces.

  • Description

    G.703 75–120 Adapter, Female with 1.6/5.6 Coax Connectors and Transformer Isolation, 2.048-Mbps


    Quick Facts

  • Solve mismatches between coax and twisted-pair equipment.
  • Make 75-ohm (dual-coax) and 120-ohm (twisted-pair) network connections.
  • Convert bidirectionally between G.703 balanced and unbalanced interfaces.

  • Further Details

  • All feature transformer isolation for protection against ground loops.
  • Choose from models that support 2.048-Mbps or 8-Mbps speeds.
  • 2.048-Mbps models can be ordered with 1.6/5.6 dual-coax connectors.

    Make bidirectional G.703 balanced and unbalanced conversions and protect against ground loops.

    Use G.703 75–120 Adapters to connect your G.703 network to your shielded twisted-pair equipment.

    These adapters address the open network provision (ONP) requirement that European post, telephone, and telegraph (PTT) authorities offer 120-ohm twisted-pair terminations to their customers.

    Use the adapters to convert the balanced G.703 signals from your bridges and routers to unbalanced G.703 signals. So you can use your 75-ohm coax hardware and communicate with 100-ohm or 120-ohm twisted-pair equipment. The adapters convert signals bidirectionally, too.

    Setup is super easy. Just plug in the adapters. If needed, you can configure the shield connection between the 75-ohm and twisted-pair interfaces.

    The G.703 75–120 Adapters support E1 data rates to 2.048 Mbps. For sending TX and RX signals over STP cable, order the MT256A-F, which has 1.6/5.6 dual-coax connectors.

    The G.703 75–120 High-Speed Adapters support data rates to 8 Mbps.

  • Technical Specifications for G.703 75–120 Adapter, Female with 1.6/5.6 Coax Connectors and Transformer Isolation, 2.048-Mbps:

    Speed (Maximum) — MT1242A-M, MT1242A-F, MT256A-F: 2.048 Mbps;
    MT260A-F, MT260A-M: 8 Mbps
    Transformer Isolation — Up to 500 volts AC/DC
    CE Approval — MT1242A-M, MT1242A-F, MT256A-F
    Interface — A: G.703 unbalanced;
    B: G.703 balanced
    Connectors — Interface A: Dual-coax BNC M or F;
    Interface B: 8-pin shielded RJ-48C
    Size — 0.8"H x 1.7"W x 2.7"D (2 x 4.3 x 6.9 cm)


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.
