Networking > Media Converters

click photo to enlarge

LMC250A-ST

Photo may show similar product

Other views

FlexPoint 100-Mbps Multimode to Single-Mode Fiber-to-Fiber Mode Converter, 1300-nm Multimode to 1300-nm Single-Mode, 5 km–28 km, ST to ST

Extend, convert, or connect 100-Mbps fiber optic segments.

LMC250A-ST

Extended Double Diamond™ Warranty Available
(Three years for two)

Product Highlights

  • Easy installation and transparent operation—no software required.
  • Between-unit connections are made over single-mode fiber so you get distance—up to 58 kilometers (36 mi.)!
  • Support 100-Mbps Ethernet.
  • Half- or full-duplex operation.

  • Description

    FlexPoint 100-Mbps Multimode to Single-Mode Fiber-to-Fiber Mode Converter, 1300-nm Multimode to 1300-nm Single-Mode, 5 km–28 km, ST to ST


    Quick Facts

  • Easy installation and transparent operation—no software required.
  • Between-unit connections are made over single-mode fiber so you get distance—up to 58 kilometers (36 mi.)!
  • Support 100-Mbps Ethernet.
  • Half- or full-duplex operation.

  • Further Details

  • Hardware available for mounting converter to a wall or a DIN rail.
  • Can also be used in the FlexPoint 14-Slot Power Chassis or the FlexPoint 5-Position Rackmount Kit.

  • FlexPoint™ Mode Converters from Black Box are versatile and cost-effective standalone converters that you can upgrade to a chassis-based system. They provide the ultimate in flexibility and reliability for your expanding multimedia LAN.

    The incredible variety and versatility of this system make it ideal for networks that are subject to constant upgrades and changes.

    Tailor the system to your requirements. Get the converters you need now and use them individually. Then, when your LAN grows, mount your converters on the wall, in the FlexPoint 5-Position Rackmounting Kit, or in the FlexPoint Power Chassis. The chassis holds 14 converters and single or dual AC or DC power supplies.


    Technical Specifications for FlexPoint 100-Mbps Multimode to Single-Mode Fiber-to-Fiber Mode Converter, 1300-nm Multimode to 1300-nm Single-Mode, 5 km–28 km, ST to ST:

    CE Approval — Yes
    Power — 110-VAC, 60-Hz, external power supply (230-VAC, 50-Hz version on request) or from Power Chassis
    Size — 1"H x 3"W x 4"D (2.5 x 7.6 x 10.2 cm)
    Weight — 0.4 lb. (0.2 kg)
    These products work with:
  • FlexPoint Power Chassis (LMC200A, etc.)
  • FlexPoint 5-Position Rackmounting Kit (LMC205)
  • FlexPoint Wallmounting Hardware (LMC206-WALL)
  • FlexPoint FlexPoint Media Converter DIN Rail Kit (LMC207-DRM)
    Also be sure to see the rest of the FlexPoint family:
  • FlexPoint 10BASE-T to BNC Media Converter (LMC210A)
  • FlexPoint 10BASE-T to 10BASE-FL Media Converters (LMC212A-MM-R3, etc.)
  • FlexPoint 100BASE-TX to 100BASE-FX Media Converters (LMC213A-MMST-R2, etc.)
  • FlexPoint Token Ring UTP to Fiber Media Converters (LTM215A)
  • FlexPoint 10/100 Rate Converters (LMC100A-R2, etc.)
  • FlexPoint Gigabit UTP to Fiber Media Converters (LMC1003A-R3, etc.)
  • FlexPoint 1000-Mbps Fiber to Fiber Mode Converters (LMC1001A, etc.)
  • FlexPoint Fiber-to-Fiber Mode Converters for ATM OC-3 and OC-12 (LMC156A-ST, etc.)
  • FlexPoint T1/E1 Copper to Fiber Line Drivers (MT660A-MM, etc.)
  • FlexPoint RS-232 to FIber Converters (ME660A-MST, etc.)
    Questions? Contact our FREE Tech Support.



    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.

  • Resources for FlexPoint 100-Mbps Multimode to Single-Mode Fiber-to-Fiber Mode Converter, 1300-nm Multimode to 1300-nm Single-Mode, 5 km–28 km, ST to ST:


    Connect your FlexPoint 100-Mbps Multimode to Single-Mode Fiber-to-Fiber Mode Converter, 1300-nm Multimode to 1300-nm Single-Mode, 5 km–28 km, ST to ST with:

    Double Diamond Warranty

    Standard Manufacturer's Warranty


    A Two year warranty is included.

    Extended Two years for one Warranty Available


    Protect your purchase with an additional Two years for oneDouble Diamond™ warranty!
    Cost: $66.90

    Extended Three years for two Warranty Available


    Protect your purchase with an additional Three years for twoDouble Diamond™ warranty!
    Cost: $133.79

    Diamond

    Double Diamond™ Warranty (Standard)

    Coverage:

    The most complete product warranty exclusively from Black Box

    The Double Diamond™ Warranty is our no-questions-asked warranty that protects your Black Box® brand products* from accidental damage, including drops, water, and power surges.

    Most products come with a one- or two-year warranty. Some products, such as copper cables, manual switches, cabinets, and racks, are guaranteed for life! Standard Warranty features are as follows:

    Worry-Free Purchases

    If your new Black Box® brand products are accidentally damaged, you're covered with this no-questions asked warranty. FREE

    Coverage

    Double Diamond™ is the standard warranty that comes with your new Black Box® brand product. Most products come with a one- or two-year warranty.

    Lifetime Guarantees

    Many products, such as copper cables, manual switches, cabinets, and racks, are guaranteed for life.

    Fast Service

    During the warranty period, Black Box® Network Services will repair or replace your damaged equipment within one week of receipt at NO CHARGE!

    Extra Coverage

    Extend your warranty or protect a previously purchased Black Box® brand product* for an additional year for only 10% of the current retail price! And when you do, we give you the second year of extended coverage free! FREE Tech Support Hotline. No cost. No contracts. No kidding!

    No-Risk 45-Day Return Policy

    If it's not right, send it back.
    (Excludes custom built products)

    * Certain products may not be eligible.

    Warranty Compared

    Black Box® Double Diamond™ Warranty The Competition
    Warranty Length One Year to Lifetime, Depending on the Product. Read the fine print.
    Guaranteed for Life! Black Box® Brand Copper Cables, Manual Switches and More! No.
    Accidental Damage 100% Covered! No.
    Water Damage 100% Covered! No.
    Power Surges 100% Covered! No.
    Warranty Replacements No Questions Asked! Forget It.
    Tech Support Hotline 100% FREE! $$$


    Add to Cart

    Price: $668.95

    Quantity

    Warranty

    Total

    In Stock

    Shipping Info

    In Stock - orders received before 8PM ET ship same day


    45-day return policy
