Cables > Specialty Cables

click photo to enlarge

EVFC-001M

Photo may show similar product

Other views

Fibre Channel Cable, 1-m (3.2-ft.)

Make Fibre Channel connections with this twisted-pair cable.

EVFC-001M


No warranty available

Product Highlights

  • Use in Fibre Channel applications for mass storage devices and other peripheral devices that require very high bandwidth.

  • Description

    Fibre Channel Cable with Molded Heads, DB9 Male/HSSDC 8-Pin Male, Unequalized, 1-m (3.2-ft.)


    Quick Facts

  • Use in Fibre Channel applications for mass storage devices and other peripheral devices that require very high bandwidth.

  • Further Details



    Technical Specifications for Fibre Channel Cable, 1-m (3.2-ft.):

    Attenuation (Maximum) 5.6 dB/30 m
    Buffer Polyolefin tape
    Conductor DC Resistance (Nominal) 0.016 ohms/ft.
    Core Solid polyethylene filler
    Diameter 0.385" ± 0.015
    Impedance (Differential) 150 ± 7 ohms
    Jacket 0.03" black PVC
    Layer 1 (4) single cables around core
    Mutual Capacitance (Nominal) 10 pF/ft.
    NEXT (Maximum) 1.5%
    Shield Inner: Aluminum/polyester tape;
    Outer: 38 AWG tin-plated copper braid, 85% coverage
    Speed (Maximum) 2.5 Gbps
    Time Delay 1.49 ns/ft. nominal
    Time Delay Skew (Maximum) 200 ps/20 m
    Wire Gauge 30 AWG


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for Fibre Channel Cable, 1-m (3.2-ft.):


    Connect your Fibre Channel Cable, 1-m (3.2-ft.) with:

    Double Diamond Warranty

    No warranty is offered on this product

    Diamond

    Double Diamond™ Warranty (Standard)

    Coverage:

    Take the risk out of equipment purchases with the Double Diamond™ Warranty from Black Box Network Services.


    The Double Diamond Warranty is our no-questions-asked warranty that protects your Black Box® brand products* from accidental damage, including drops, water, and power surges.

    Most of our products come with a one- or two-year warranty. Some products—such as copper cables, manual switches, cabinets, and racks—are even guaranteed for life!

    During the warranty period, Black Box Network Services will repair or replace your damaged equipment within one week of receipt at NO CHARGE!

    Plus, get an Extended Double Diamond Warranty.


    You can also extend your warranty or protect a previously purchased Black Box® brand product* for an additional year—for only 10% of the purchase price! Or, extend your coverage for a full three years for only 20% of the purchase price!

    Ordering an extended warranty is easy: When viewing a product in your shopping cart, just select the one or three years of additional coverage in the dropdown menu under “Warranty Options.” For details, contact Customer Service at 724-746-5500.

    * Certain products may not be eligible.

    Warranty Compared

    Black Box® Double Diamond™ Warranty The Competition
    Warranty Length One Year to Lifetime, Depending on the Product. Read the fine print.
    Guaranteed for Life! Black Box® Brand Copper Cables, Manual Switches and More! No.
    Accidental Damage 100% Covered! No.
    Water Damage 100% Covered! No.
    Power Surges 100% Covered! No.
    Warranty Replacements No Questions Asked! ?
    Tech Support Hotline 100% FREE! $$$

    What’s more, we also have a 45-day, no-questions-asked return policy. Simply call Customer Service for a Return Authorization (RA) number, return your product in new condition and in the original package, and receive a full refund.

    You can find this product in the following subcategory(s)


    Price: $58.95

    Quantity Available: 1

    To order please call
    1-877-877-2269

    Shipping Info

    call 1-877-877-2269

    Weight: 0.15 lbs.
    HxWxD: 0.5 x 5.5 x 5.5 in.
