Datacom > Switches

click photo to enlarge

SW1008A

Photo may show similar product

Other views

Fiber Optic A/B Switch, Latching, SC

For ultra-secure, critical-circuit switching, use these micro-mirror optical devices.

SW1008A

Extended Double Diamond™ Warranty Available
(Three years for two)

Product Highlights

  • No optical-to-electrical conversion between fiber connections. Instead, the switches use internal mirrors to optically move data between ports—technology that’s trusted and time tested!


    • Description

    Fiber Optic A/B Switch, Latching, SC


    Quick Facts

  • No optical-to-electrical conversion between fiber connections. Instead, the switches use internal mirrors to optically move data between ports—technology that’s trusted and time tested!

    • Further Details

  • Simple to use. To route signals, just turn a knob on the front panel.
  • Ideal for government, healthcare, financial, or other applications where a private, data-sensitive network connects to a publicly accessible network.
  • For reliable switching in mission-critical environments, the micro-mirrors are bonded to precise positioning servos.
  • Enable you to connect a single workstation to two or more networks or remote devices.
  • Latching switches latch mirror movement mechanically into a selected position and hold it there without the need for continuous electrical power.
  • All non-latching versions except for the SW1003A fall back to C-to-A position if power is lost (the SW1003A falls back to the OFF position).
  • The OFF position on the SW1003A also prevents host-to-remote device communications.
  • Models with loopback enable you to test an idle fiber link from a central office to ensure that the circuit is operating correctly.
  • Operate transparently to signal rates, formats, and wavelengths, and don’t require an upgrade when your data protocols change or speeds increase.
  • Work with 62.5-/125-micron multimode.
  • Universal 100–240-VAC power supply.

    • There’s a reason why these types of manual switches continue to be the switches of choice for networking professionals everywhere: The tried-and-true optical switches perform as promised year after year.

    They’re reliable because they use micro-mirrors instead of electronics to route data signals from one fiber optic port to the next. And unlike conventional electronic switches, there are no complex and vulnerable electronic circuits to monitor and protect from intrusion, component failure, or interference.

    The switches are available in latching and non-latching models. The optical mirror movement on the latching versions maintain the selected position even when there’s a power failure.

    You can also order an A/B switch with unique loopback capabilities. Using loopbacks, you can verify the integrity of your backup fiber link while still connected to your primary fiber link. This is especially useful in failover applications where you want to continuously test the “unused” circuit to ensure that it’s available if needed.


    Technical Specifications for Fiber Optic A/B Switch, Latching, SC:

    Compatibility — 62.5-/125-micron multimode fiber
    Crosstalk — -45 dB (typical) per FOTP-42
    MTBF — 100,000 hours or 1,000,000 cycles
    Optical Loss — 0.5 dB (typical) at 1300 nm per FOTP-34 method B
    Sensitivity — 750 to 1440 nanometers
    Switching Speed — Typical: 5 msec;
    Maximum: 10 msec
    CE Approval — Yes
    Connectors — Fiber ports: SW1000A, SW1002A–SW1003A, SW1010A: (3) pairs of ST®;
    SW1008A–SW1009A: (3) pairs of SC
    Power: All: (1) 3.5-mm input
    Power — Input: 100–240 VAC, 50–60 Hz, autosensing;
    Output: 5 VDC
    Size — SW1000A, SW1002A, SW1008A: 2.5"H x 8"W x 6.3"D (6.4 x 20.3 x 16 cm);
    SW1003A: 3.5"H x 19"W x 6.5"D (8.9 x 48.3 x 16.5 cm);
    SW1009A–SW1010A: 2.5"H x 8.1"W x 10.8"D (6.4 x 20.6 x 27.4 cm)
    Weight — SW1000A, SW1002A, SW1008A: 4 lb. (1.8 kg);
    SW1003A: 7 lb. (3.2 kg);
    SW1009A–SW1010A: 2.5 lb. (1.1 kg)


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.
