Infrastructure Hardware > Adapters

click photo to enlarge

FCPC05

Photo may show similar product

Other views

FC/PC Fiber Optic In-Line Attenuators, 5-dB

Buffer overpowering fiber signals and eliminate errors.

FCPC05


Five year Warranty

Product Highlights

  • High-precision doping technology for low back reflection and increased fiber signal accuracy.
  • Ideal for use in CATV, LAN, WAN, and telecommunications applications.
  • Precision zirconia alignment sleeve.

  • Description

    Fiber Optic In-Line Attenuators, Single-Mode, Male/Female, FC/PC, 5-dB


    Quick Facts

  • High-precision doping technology for low back reflection and increased fiber signal accuracy.
  • Ideal for use in CATV, LAN, WAN, and telecommunications applications.
  • Precision zirconia alignment sleeve.

  • Further Details

  • Guaranteed return loss of -55 dB.
  • Protect equipment from being overpowered.
  • Choose from three fixed attenuation values.


  • Fiber equipment located too close to other fiber equipment? Having problems with transmissions? Data being corrupted? Getting system failures? The problem is easier to fix than you may think.

    When a fiber device is very close to another one—for example, as little as 3 feet (0.9 m)—the signal is extremely strong. The light signal doesn’t have time to attenuate or lose strength as it travels down the fiber. This is called receive saturation. The energy level of the fiber optic signal is too high and exceeds the operating range of the receiving equipment. So when the light reaches the other end, it reflects back along the cable. This reflection distorts the signal and disrupts data.

    Solve the problem with our attenuators. They feature guaranteed return-loss measures to attenuate the signal. To achieve the fixed return loss, the attenuators use a doped single-mode fiber with a wavelength of 1310–1550 nm.

    Use the attenuators in CATV, LAN, WAN, and telecommunications applications. When you have multiple fiber runs, use the attenuators to make sure all are operating at the same optical level. You can also use the attenuators as part of your test kits to verify optical levels.


    Technical Specifications for FC/PC Fiber Optic In-Line Attenuators, 5-dB:

    Attenuation — 2, 5, or 10 dB
    Attenuation Tolerances — 2 or 5 dB: ± 1.0 dB; 10 dB: ± 1.5 dB
    Cable Type — Single-mode fiber optic
    Return Loss —-55 dB typical
    Wavelength — 1310/1550 nm
    Connectors — FC with PC


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for FC/PC Fiber Optic In-Line Attenuators, 5-dB:


    Connect your FC/PC Fiber Optic In-Line Attenuators, 5-dB with:
