Cabinets & Racks > Wallmount & Specialty Cabinets

click photo to enlarge

EWM12U242418-M-R2

Photo may show similar product

Other views

Elite Wallmount Cabinet, 24"H (12U) x 24"W x 18"D, Mesh FrontElite Wallmount Cabinet, 24"H (12U) x 24"W x 18"D, Mesh Front

Mesh front door help keeps equipment cool.

EWM12U242418-M-R2

Extended Double Diamond™ Warranty Available
(Lifetime)

Product Highlights

  • Large openings in back panel enable you to easily install patch panels or other prewired equipment.
  • Accessories that fit the 3U opening in our full-sized Elite Cabinets also fit into this cabinet's 3U opening.
  • Mesh front door helps keep equipment cool.
  • Also available in 20U and 26U models.
  • Guaranteed for life!

  • Description

    Elite Wallmount Cabinet, 24"H (12U) x 24"W x 18"D, Mesh Front


    Quick Facts

  • Large openings in back panel enable you to easily install patch panels or other prewired equipment.
  • Accessories that fit the 3U opening in our full-sized Elite Cabinets also fit into this cabinet's 3U opening.
  • Mesh front door helps keep equipment cool.
  • Also available in 20U and 26U models.
  • Guaranteed for life!

  • Further Details

  • Doors can be reversed to open left or right.
  • Double hinged for easy access to rear of equipment.
  • Has keylocks on front and side.
  • Ships with one conduit panel.
  • Includes one pair of 10-32 rails. Order additional rails for 4-point mounting.


  • The newest member of the Elite™ family of cabinets from Black Box has all the quality you've come to expect plus new features that set it apart from other wallmount cabinets, including a mesh front door to help keep equipment cool.

    Easily add equipment.
    This Elite Wallmount Cabinet features large openings on the back panel that enable you to simply slide in a loaded patch panel.

    Accessorize.
    If you want to add fans, a Brush Grommet Kit, a Waterfall Radius Bracket, or other accessory, it couldn't be easier. That's because just about any Elite accessory that fits into the 3U opening on the top of our full-sized Elite cabinets will also work with the wallmount cabinet.

    Add a Brush Grommet Kit (ECBGK3U) to run cable into the cabinet while protecting the interior of the cabinet from dust and debris. Install a fan (RMT373-R2) to increase air circulation and keep equipment cool. Attach a waterfall bracket (ECW3U) to maintain bend radius when routing cable into the top of the cabinet. And more!

    For even more versatility, optional brackets attach to the back panel of the cabinet and enable you to rackmount patch panels behind the equipment in the cabinet at 45° or 90° angles.



    Technical Specifications for Elite Wallmount Cabinet, 24"H (12U) x 24"W x 18"D, Mesh FrontElite Wallmount Cabinet, 24"H (12U) x 24"W x 18"D, Mesh Front:

    Interior Width 23.75" (60.3 cm)
    Main Body Depth 9.125" (23.2 cm)
    Rack Units 12U
    Rear Section Depth 7" (17.8 cm)
    Size 24"H x 24"W x 18"D

    This cabinet works with:
  • Brush Grommet Kit (ECBGK3U)
  • Waterfall Radius Bracket (ECW3U)
  • Fan (RMT373-R2)
  • Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for Elite Wallmount Cabinet, 24"H (12U) x 24"W x 18"D, Mesh FrontElite Wallmount Cabinet, 24"H (12U) x 24"W x 18"D, Mesh Front:


    Connect your Elite Wallmount Cabinet, 24"H (12U) x 24"W x 18"D, Mesh FrontElite Wallmount Cabinet, 24"H (12U) x 24"W x 18"D, Mesh Front with:

    Accessory: ECBGK3U

    Elite Cabinet Brush Grommet Kit for 3U Opening

    Elite Cabinet Brush Grommet Kit for 3U Opening

    Accessory: ECW3U

    Elite Cabinet Waterfall Brackets for 3U Top Opening

    Elite Cabinet Waterfall Brackets for 3U Top Opening

    Accessory: RMT373-R2

    4.5" Cooling Fan for Low-Profile Secure Wallmount Cabinets

    4.5" Cooling Fan for Low-Profile Secure Wallmount Cabinets

    Accessory: EWM45DAB

    Elite Wallmount Cabinet 45° Angle Bracket

    Elite Wallmount Cabinet 45° Angle Bracket

    Accessory: EWM90DAB

    Elite Wallmount Cabinet 90° Angle Bracket

    Elite Wallmount Cabinet 90° Angle Bracket

    Double Diamond Warranty

    Standard Manufacturer's Warranty


    A warranty is included.

    Diamond

    Double Diamond™ Warranty (Standard)

    Coverage:

    Take the risk out of equipment purchases with the Double Diamond™ Warranty from Black Box Network Services.


    The Double Diamond Warranty is our no-questions-asked warranty that protects your Black Box® brand products* from accidental damage, including drops, water, and power surges.

    Most of our products come with a one- or two-year warranty. Some products—such as copper cables, manual switches, cabinets, and racks—are even guaranteed for life!

    During the warranty period, Black Box Network Services will repair or replace your damaged equipment within one week of receipt at NO CHARGE!

    Plus, get an Extended Double Diamond Warranty.


    You can also extend your warranty or protect a previously purchased Black Box® brand product* for an additional year—for only 10% of the purchase price! Or, extend your coverage for a full three years for only 20% of the purchase price!

    Ordering an extended warranty is easy: When viewing a product in your shopping cart, just select the one or three years of additional coverage in the dropdown menu under “Warranty Options.” For details, contact Customer Service at 724-746-5500.

    * Certain products may not be eligible.

    Warranty Compared

    Black Box® Double Diamond™ Warranty The Competition
    Warranty Length One Year to Lifetime, Depending on the Product. Read the fine print.
    Guaranteed for Life! Black Box® Brand Copper Cables, Manual Switches and More! No.
    Accidental Damage 100% Covered! No.
    Water Damage 100% Covered! No.
    Power Surges 100% Covered! No.
    Warranty Replacements No Questions Asked! ?
    Tech Support Hotline 100% FREE! $$$

    What’s more, we also have a 45-day, no-questions-asked return policy. Simply call Customer Service for a Return Authorization (RA) number, return your product in new condition and in the original package, and receive a full refund.

    You can find this product in the following subcategory(s)


    Add to Cart

    Price: $634.95

    Quantity Available: 0

    Quantity

    Warranty

    Total

    Shipping Info

    Weight: 107.25 lbs.
    HxWxD: 26 x 20.5 x 26.5 in.

    What’s more, we also have a 45-day, no-questions-asked return policy. Simply call Customer Service for a Return Authorization (RA) number, return your product in new condition and in the original package, and receive a full refund.
