EVNPS80-0150

Photo may show similar product

Other views

Easy-Pull VGA Cable, 150-ft. (45.7-m)

Run VGA cable through walls or inside tight conduits. This cable goes 150 feet or more!

EVNPS80-0150

Extended Double Diamond™ Warranty Available
(Lifetime)

Product Highlights

  • Panel-mount HD15 connector works perfectly with our DB9 Stainless Steel Wallplates.
  • Perfect for system integration.
  • Guaranteed for life!

  • Description

    Easy-Pull VGA Cable, 150-ft. (45.7-m)


    Quick Facts

  • Panel-mount HD15 connector works perfectly with our DB9 Stainless Steel Wallplates.
  • Perfect for system integration.
  • Guaranteed for life!

  • Further Details

  • Connect PC or RGB video sources to display devices like projectors, flat plasma screens, and more.
  • Provide 1024 x 768 video resolution up to 150 feet and 800 x 600 video resolution up to 200 feet.
  • Super flexible! They can be pulled through 3/4" conduits, and they make pull times faster.
  • Includes heat shrink tubing for permanent installation.
  • Available in six standard lengths as well as custom lengths.
  • Plenum-rated jacket.

  • When you need to transmit high-resolution SVGA video but have to route cable behind a wall or inside a conduit, choose our BLACK BOX® Easy-Pull VGA Cable.

    The cable is perfect for system integration and can connect PC or RGB video to display devices such as projectors, video walls, flat plasma screens, and monitors. It maintains excellent signal strength and provides 1024 x 768 resolution up to 150 feet (45.7 m) and 800 x 600 resolution up to 200 feet (60.9 m).

    Designed with a proprietary construction, Easy-Pull VGA Cable is flexible and simplifies system integration. It’s perfect for tight spaces and shortens pull time. In fact, the cable’s construction enables it to be pulled through a 3⁄4" conduit!

    The jacket is plenum rated. It also comes with heat shrink tubing to connect the 6-pin mini DIN permanently.


    Technical Specifications for Easy-Pull VGA Cable, 150-ft. (45.7-m):

    Attenuation 4.65 dB/100 ft. (30.4 m) nominal at 100 MHz
    Cable Construction 26 AWG tinned, stranded copper
    Capacitance 16.3 pF/ft. nominal
    Impedance 75 ohms nominal
    Insulation Natural foamed fluorinated ethylene propylene, 0.072" (0.2 cm) diameter
    Jacket OFNP PVC
    Resistance 40 ohms/1000 ft. (304.8 m)
    Resolution (Maximum) 1024 x 768: 150 ft. (45.7 m);
    800 x 600: 200 ft. (60.9 m)
    Shield Inner: Aluminum/polyester tape;
    Outer: Spiral 38 AWG tinned copper, 97% coverage
    Time Delay 1.20 ns/ft. nominal
    Velocity of Propagation 85%
    Connectors (1) HD15 M; (1) removable HD15 F; (1) 6-pin DIN M; (1) 6-pin DIN F

    These products work with:
    • Stainless Steel DB9 Wallplates (WP070–WP073)
    Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for Easy-Pull VGA Cable, 150-ft. (45.7-m):

    Application Diagrams


    Connect your Easy-Pull VGA Cable, 150-ft. (45.7-m) with:
