LES8324A-2AC

Photo may show similar product

Other views

Dual 10/100/1000 Secure Console Server, 32-Port with Dual Power Supply

Console servers with superior encryption and support for dual Gigabit Ethernet.

LES8324A-2AC

Extended Double Diamond™ Warranty Available (3 Additional Year)

Product Highlights

  • The right choice when fail-safe operation is a priority!
  • Access up to 32 serial console ports securely over your Ethernet network.
  • RS-232 ports with an RJ-45 interface.


  • Further Details

  • Dual 10-/100-/100-Mbps Ethernet ports.
  • Optional dual power inputs.
  • Secure access to RS-232 serial console ports across your Ethernet network.
  • Dual Gigabit Ethernet ports plus optional dual power inputs for maximum redundancy.
  • The PCI port supports a V.92 modem for emergency access in case of complete network failure.
  • Features a powerful 400-Mhz, 750-MIPS, 32-bit processor.
  • Easy to manage through any Web browser or Telnet™.
  • Secured with 128-, 192- and 256-bit AES, 3DES, Blowfish, and CAST128, plus ARCFOUR or ARCTWO data encryption across the LAN via SSH and SSL.
  • Advanced user authentication through RADIUS, TACACS+, LDAP, Kerberos, NIS, and RSA.
  • Manageable through Windows® Device Manager, HTTP, HTTPS/SSL/TLS, SSH, or Telnet.
  • Includes COMredirect software to provide true remote serial ports over an Ethernet LAN.
  • Supports e-mail event notification.
  • Syslog support enables you to track system events for routine troubleshooting and incident handling.
  • The sturdy steel chassis is only 1U high and can be front- or rear-mounted.
  • Built-in surge protection on all interfaces.


  • Dual 10/100/1000 Secure Console Servers enable you to use your Ethernet network to securely access remote serial console ports on equipment such as PBXs, servers, routers, or network storage equipment. Dual Gigabit Ethernet ports provide network redundancy for mission-critical applications. Plus, optional dual power inputs enable you to provide a secondary power source for increased uptime.

    The servers protect sensitive data from serial devices such as credit card readers through encryption with Secure Shell (SSH) and Secure Sockets Layer (SSL). The console servers also support all major encryption ciphers such as AES, 3DES, RC4, RC2, and CAST128. User authentication through RADIUS, TACACS+, LDAP, Kerberos, NIS, and RSA Security's SecurID tokens ensures that only authorized users can access the system.

    The integrated hardware encryption processor performs encryption and decryption at many times the speed of software encryption and frees the main processor to convert Ethernet and serial signals.

    Secure Console Servers support Next Generation IP (IPv6), making them compatible with networks that have upgraded to this new IP standard. Plus the included COMredirect software provides fixed TTY or COM ports so server-based applications can communicate accurately with serial devices in encrypted or clear text modes. The console servers also support SNMP for integration into managed networks.

    Secure Console Servers include Device Manager software to provide central control of multiple terminal servers, so you get maximum uptime for your remote equipment.


    Environmental Operating temperature: +32 to +131° F (0 to +55° C);
    Storage temperature: -40 to +150° F (-40 to +66° C)
    Management Web browser; Device Manager software (included); Telnet, shared console port; SNMP, MIB II, read and write Syslog
    Port Buffering 256K per port or 3DES encrypted to NFS server
    Processor 400 MHz, 750 MIPS, 32-bit
    Protocols IPv6, IPv4, TCP/IP, Reverse SSH, SSH, SSL, CIDR, RIPV2/MD5, ARP, RARP, UDP, UDP Multicast, ICMP, BOOTP, DHCP, TFTP, SNTP, Telnet, raw, reverse Telnet, LPD, RCP, DNS, WINS, HTTP, HTTPS, SMTP, SNMPV3, PPP, PAP/CHAP, SLIP, CSLIP
    Security and Authentication SSHV1 and SSHV2; SSL V3.0/TLS V1.0, SSL V2.0 SSL Server and SSL client mode capability;
    Encryption: AES (256/192/128), 3DES, DES, Blowfish, CAST128, ARCFOUR(RC4), ARCTWO(RC2);
    Hashing Algorithms: MD5, SHA-1, RIPEMD160, SHA1-96, and MD5-96;
    Key exchange: RSA, EDH-RSA, EDH-DSS, ADH;
    X.509 Certificate verification: RSA, DSA;
    Certificate authority (CA) list; Local database; RADIUS Authentication and Accounting; TACACS+, LDAP, NIS, Kerberos; RSA SecureID-agent or via RADIUS; IP Address filtering; Disable unused daemons
    Serial Ports EIA-232, RJ-45 connectors, full modem and hardware flow control, 50 bps to 230 kbps, Sun® Break Safe, full bidirectional modem support, 15Kv ESD protection on all signals
    CE Approval Yes
    Interface Serial: RS-232;
    Network: 10/100/1000BASE-TX
    Connectors LES8084A, LES8084A-2AC: (2) RJ-45 10-/100-/1000-Mbps Ethernet, (8) RJ-45 RS-232, (1) PCI;
    LES8164A, LES8164A-2AC: (2) RJ-45 10-/100-/1000-Mbps Ethernet, (16) RJ-45 RS-232, (1) PCI;
    LES8324A, LES8324A-2AC: (2) RJ-45 10-/100-/1000-Mbps Ethernet, (24) RJ-45 RS-232, (1) PCI
    Indicators LEDs: Per unit: (1) Power, (1) System Ready;
    Per Ethernet port: (1) Network Link activity;
    Per serial port: (1) Tx and Rx data
    Power Autosensing 100-240 VAC, 50-60 Hz with single or dual IEC 320 inputs
    Size 1.75"(1U)H x 17.1"W x 10.4"D (4.4 x 43.4 x 26.4 cm)
    Weight LES8084A: 6.6 lb. (3 kg);
    LES8084A-2AC, LES8324A: 7 lb. (3.2 kg);
    LES8164A: 6.8 lb. (3.1 kg);
    LES8164A-2AC: 7.5 lb. (3.4 kg);
    LES8324-2AC: 7.7 lb. (3.5 kg)


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 1-800-316-7107.

    Product Data Sheets

    Firmware

    • Terminal & Conole Server Firmware
      Firmware for LES4011A%X96LES4014A, LES5011A%X96LES5016A, LES6044A, LES6045A LES7044A, LES7084A, LES7164A, LES7244A LES8084A, LES8084A-2AC LES8164A, LES8164A-2AC LES8324A, & LES8324A-2AC

    Black Box Explains


    Accessory: LCA102

    Secure Device Server Serial Adapter, RJ-45 to PC DB25 Female

    Secure Device Server Accessories, Serial Adapter, RJ-45 to PC DB25 Female

    Accessory: LCA103

    Secure Device Server Serial Adapter, RJ-45 to PC DB9 Female

    Secure Device Server Serial Adapter, RJ-45 to PC DB9 Female

    Accessory: LCA104

    Secure Device Server Serial Adapter, RJ-45 to Modem DB25 Male

    Secure Device Server Serial Adapter, RJ-45 to Modem DB25 Male

    Accessory: LCA105

    Secure Device Server Serial Adapter, RJ-45 to Printer DB25 Male

    Secure Device Server Serial Adapter, RJ-45 to Printer DB25 Male

    Accessory: LCA106

    Secure Device Server Serial Adapter, RJ-45 to Sun/Cisco RJ-45

    Secure Device Server Serial Adapter, RJ-45 to Sun®/Cisco® RJ-45

    Double Diamond Warranty
    Extended Double Diamond™ Warranty Available (3 Additional Year)
    Diamond

    Double Diamond™ Warranty (Standard)

    Coverage:

    Take the risk out of equipment purchases with the Double Diamond™ Warranty from Black Box Network Services.


    The Double Diamond Warranty is our warranty that protects your Black Box® brand products* from accidental damage, including drops, water, and power surges.

    The Dual 10/100/1000 Secure Console Server, 32-Port with Dual Power Supply comes with a standard 1 Year warranty already included.

    During the warranty period, Black Box Network Services will repair or replace your damaged equipment within one week of receipt at NO CHARGE!*

    Plus, get an Extended Double Diamond Warranty.


    You can also extend your warranty or protect a previously purchased Black Box® brand product** for an additional year—for only 10% of the purchase price! Or, extend your coverage for a full three years for only 20% of the purchase price!

    Ordering an extended warranty is easy: When viewing a product in your shopping cart, just select the one or three years of additional coverage in the dropdown menu under “Warranty Options.” For details, contact Customer Service at 724-746-5500.

    * Warranty subject to certain exclusions and limitations
    ** Certain products may not be eligible.

    What’s more, we also have a 45-day return policy. Simply call Customer Service for a Return Authorization (RA) number, return your product in new condition and in the original package, and receive a full refund.

    Product SKU Price Quantity
    Dual 10/100/1000 Secure Console Server, 8-Port LES8084A $1,398.80

    Dual 10/100/1000 Secure Console Server, 16-Port LES8164A $1,805.85

    Dual 10/100/1000 Secure Console Server, 16-Port, Dual Power Supply LES8164A-2AC $2,331.05

    Dual 10/100/1000 Secure Console Server, 32-Port LES8324A $2,563.35
