Cabinets & Racks > Wallmount & Specialty Cabinets

click photo to enlarge

RMW5120AF

Photo may show similar product

Other views

ClimateCab NEMA 12 Wallmount Cabinet with Fan, Beige, Single-Hinged

This secure wallmount cabinet features a built-in fan for ventilation.

RMW5120AF

Extended Double Diamond™ Warranty Available
(Three years for two)

Product Highlights

  • Top mounted 6-inch fan provides airflow to help dissipate heat generated by your equipment.
  • NEMA 12 rated for protection against falling dirt, circulating dust, lint, and debris, and dripping or splashing liquids in indoor environments.
  • Includes one set of standard 19" rails with 12-24 tapped mounting holes.

  • Description

    ClimateCab NEMA 12 Wallmount Cabinet with Fan, Beige, Single-Hinged


    Quick Facts

  • Top mounted 6-inch fan provides airflow to help dissipate heat generated by your equipment.
  • NEMA 12 rated for protection against falling dirt, circulating dust, lint, and debris, and dripping or splashing liquids in indoor environments.
  • Includes one set of standard 19" rails with 12-24 tapped mounting holes.

  • Further Details

  • Air filters on the bottom of the unit can be easily removed for cleaning without opening the cabinet.
  • Scratch-resistant safety glass window for easy viewing of indicators.
  • Shroud protects the cabinet and its fan from falling debris or dripping water.
  • Robust 12-gauge frame and 14-gauge sides and doors.
  • Seamless door gasket keeps out dust and contaminants.
  • Door lock with two keys.
  • Plenum rated.
  • Go green — Save energy and money by cooling only the cabinet rather than a whole room or IT center.

  • When you need to install rackmount equipment in areas where you need protection from the elements, but temperature control is not an issue, the ClimateCab NEMA 12 Wallmount Cabinet is your answer. It’s sealed against dripping water and dust.

    On this single-hinged model, only the front door opens. Also available is a double-hinged model (RMW5100AF) in which the cabinet swings away from a rear door, enabling access to the rear of your equipment.


    Technical Specifications for ClimateCab NEMA 12 Wallmount Cabinet with Fan, Beige, Single-Hinged:

    Construction — Body: Welded 14-gauge steel;
    Front Door: 14-gauge steel with safety glass window;
    Back Door: 14-gauge steel
    Rack Units — 12U
    Size — 24"H x 24"W x 24"D (61 x 61 x 61 cm)
    Power — 115-VAC, 50–60 Hz, standard NEMA 15 A plug internal to the cabinet (5-15P)
    Weight Capacity — 100 lb. (45.4 kg)


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.
