ClimateCab NEMA 12 Wallmount Cabinet with 800-BTU Air-Conditioner, Beige, Single-Hinged

Secure wallmount protection with 800-BTU air conditioning for total climate control.


1 YEAR DoubleDiamond™ Warranty (Standard)

Product Highlights

  • NEMA 12 rated for protection against falling dirt; circulating dust, lint, and debris; and dripping or splashing liquids in indoor environments.
  • Perfect for harsh environments and remote locations without cooling infrastructure.
  • Includes one set of standard 19" rails with 10-32 tapped mounting holes.
  • Scratch-resistant safety glass window for easy viewing of indicators.

  • Further Details

  • Fully welded body and door construction.
  • Robust 12-gauge frame and 14-gauge sides and doors.
  • Seamless door gasket keeps out dust and contaminants.
  • Closed-loop cooling system recirculates air in the cabinet and keeps outside air out.
  • Side mounted 800-BTU air-conditioning unit keeps your equipment cool in temperatures up to 130° F (54º C)
  • Internal evaporator eliminates condensation.
  • Shroud protects the cabinet and its fan from falling debris or dripping water.
  • Door lock with two keys.
  • Plenum rated.
  • Go green — save energy and money by cooling only the cabinet rather than a whole room or IT center.

  • When you need to install rackmount equipment in less-than-ideal environments or in areas without existing cooling infrastructure, the ClimateCab™ NEMA 12 Wallmount Cabinet is your answer. Its self-contained cooling system keeps your equipment housed in ideal conditions in virtually any location.

    The cabinet is also sealed against contaminants such as dripping water and dust.

    On this double-hinged model, the cabinet swings away from either a front or a rear door, enabling access to the rear of your equipment. It's available as a single-hinged model (RMW5130AC) in which only the front door opens.

    NOTE: Ships assembled without the air-conditioning (AC) unit mounted. Mounting the AC unit takes about two minutes.

    Construction Body: Welded 14-gauge steel;
    Front Door: 16-gauge steel with safety glass window;
    Back Door: 16-gauge steel
    Rack Angles: 12-gauge steel
    Rack Units 12U
    Power 115-VAC, 50-60 Hz, standard NEMA 15 A plug internal to the cabinet (5-15P)
    Dimensions (Excluding AC Unit) 24.09"H x 23.62"W x 27.95"D (61.19 x 60 x 71 cm)
    Weight Capacity 250 lb. (113.4 kg)

    NOTE: Ships assembled without the air-conditioning unit mounted. Mounting the AC unit takes about two minutes.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 1-800-316-7107.


    • ClimateCab NEMA 12 Wallmount Cabinet, with 800-BTU Air-Conditioner, User Manual
      User Manual for the RMW5110AC-R2 (Version 1)

    Visio Stencils

    • Visio Stencil
      Stencil Drawings

    Black Box Explains


    • ClimateCab Cabinets
      Climate-Controlled Cabinets: Cool the cabinet, not the room. (Version 4)
