CAT6 Industrial Patch Cords, 5-ft. (1.5-m)

For CAT6 patches in harsh environments, use this tough cable!

EVNSLI05-0005

Extended Double Diamond™ Warranty Available
(Lifetime)

Product Highlights

  • Extend data transmissions to areas with temperature extremes, chemical exposure, dust, moisture, vibration, and heavy-duty everyday wear-and-tear.
  • Guaranteed for life!

  • Description

    CAT6 Industrial Patch Cords, 500-MHz, Stranded, 24 AWG, PVC, Gray, Industrial to Industrial, 5-ft. (1.5-m)


    Quick Facts

  • Extend data transmissions to areas with temperature extremes, chemical exposure, dust, moisture, vibration, and heavy-duty everyday wear-and-tear.
  • Guaranteed for life!

  • Further Details

  • Stranded 24 AWG cable terminated with industrial-to-industrial connectors or industrial-to-standard RJ-45 connectors.
  • Cables and jacks meet or exceed TIA/EIA-568-B.2-1 (CAT6) standards.
  • Flexible double-jacketed PVC offers extra protection.
  • Maximum strain relief prevents accidental disconnects from industrial vibration.
  • Protect RJ-45 CAT6 connections from dust, oil, water, and other contaminants.
  • Ideal for use in areas where cable terminations are exposed to regular abuse.

    Ethernet cabling is fine for your corporate office, but if you want to expand into areas less friendly to data transmissions—areas where temperature extremes, electromagnetic interference (EMI), and everyday wear-and-tear can take a toll on your data communications, you need something more.

    For cable-to-wall jack connections in this environment, standard RJ-45 cable connections just won't do. Demanding industrial and harsh commercial applications need the BLACK BOX® Industrial Connection System.

    This end-to-end solution includes cables, connectors, enclosures, and wallplates and is based on a bayonet-style connector designed to keep your UTP wall terminations safe and secure.



  • Technical Specifications for CAT6 Industrial Patch Cords, 5-ft. (1.5-m):

    Attenuation 24.2 dB/100 m at 350 MHz
    Cable Diameter 1" (2.54 cm)
    Cable Type 4-pair, stranded twisted-pair copper in a double PVC jacket
    Conductor Gauge 24 AWG
    Impedance 100 ±15 ohms
    Mutual Capacitance (Maximum) 56 pF/100 m (nominal)
    Standards TIA/EIA-568-B.2
    Wiring T568A, T568B

    These products work with:
  • Industrial Panel-Mount Connector Cover (FMI010)
  • Stainless Industrial Wallplates (WPI001)
  • Secure Industrial NEMA 3R Box with Slide-Up Cover (WPI055)
  • Industrial Panel-Mount Connector Housing (FMI001)
    Questions? Contact our FREE Tech Support.


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.

  • Resources for CAT6 Industrial Patch Cords, 5-ft. (1.5-m):

    Product Data Sheets
