CAT5 Audio/Visual Computer Training System 8-Port Broadcaster

Sends video and mono audio signals to hundreds of displays.

AC156A-8

Extended Double Diamond™ Warranty Available
(3 Additional Year)

Product Highlights

  • Ideal for broadcasting real-time information in airports, train stations, stock exchanges, trade shows, security systems, and more.


  • Description

    CAT5 Audio/Visual Computer Training System 8-Port Broadcaster


    Quick Facts

  • Ideal for broadcasting real-time information in airports, train stations, stock exchanges, trade shows, security systems, and more.

  • Further Details

  • "Darken All" feature enables an instructor to darken all remote monitors.
  • Sends video and mono audio signals to hundreds of displays.
  • For simple systems, connect the 8-Port Broadcaster directly to the remote units. To broadcast from 8 to 512 remote displays, add 1 or 2 levels of splitters.
  • Great for schools, universities, or any classroom training application.
  • Send a screen to the entire class (up to 64 remotes) or just 1 student display at the push of a button.
  • Supports VGA video up to 1600 x 1200 at 75 Hz—up to 360 feet (109.7 m).
  • Also supports two-way audio, CHAT, and messaging between connected PCs.
  • Windows® compatible. Communicates with PCs that have 100BASE-T network cards installed.

  • What's includes:
  • (1) power supply with (1) U.S. cord and (1) European cord
  • (1) control unit
  • (2) speaker/microphone cables
  • (1) VGA cable
  • (1) user's manual

  • Technical Specifications for CAT5 Audio/Visual Computer Training System 8-Port Broadcaster:

    Audio Mono
    Network Requirements 100BASE-T environment running TCP/IP
    Resolution (Maximum) 1600 x 1200 @ 75 Hz
    Power 115-230 VAC, 50-60 Hz, autosensing, external
    Size 1.7"H x 6.9"W x 3.8"D (4.3 x 17.5 x 9.7 cm)
    NOTE: This broadcaster can be integrated into the complete CAT5 Audio/Video Training Kit (AC164A). To purchase and use components separately, first order one broadcaster (AC156A-8) or one transmitter (AC165A). Next, order one CAT5 Audio/Video Remote Unit for each display. Choose either the AC158A-REM or AC158A-PWREM. Last, for system expansion, order a CAT5 Audio/Video Splitter (AC157A-8).

    This product works with:
  • CAT5 Solid-Conductor Cable (EYN737MS)
  • Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for CAT5 Audio/Visual Computer Training System 8-Port Broadcaster:

    Manuals

    • CAT5 Audio/Video 8-Port Broadcaster CAT5 Audio/Video Splitter CAT5 Audio Video Remote
      Installation/User (Oct-02)

    Product Data Sheets


    Connect your CAT5 Audio/Visual Computer Training System 8-Port Broadcaster with:

    Accessory: AC157A-8

    CAT5 Audio/Video Computer Training System 8-Port Splitter

    CAT5 Audio/Video Computer Training System 8-Port Splitter

    Accessory: AC158A-PWREM

    CAT5 Audio/Video Computer Training System Powered Remote Unit

    CAT5 Audio/Video Computer Taining System Powered Remote Unit

    Accessory: AC158A-REM

    CAT5 Audio/Video Computer Training System Remote

    CAT5 Audio/Video Computer Training System Remote

    Accessory: EYN556MS-0010

    CAT5e Solid-Conductor Patch Cable, PVC, Straight-Pinned, Beige, 10-ft. (3.0-m)

    CAT5e Solid-Conductor Patch Cable, PVC, Straight-Pinned, Beige, 10-ft. (3.0-m)
