Power > UPS

click photo to enlarge

SUA3000XL

Photo may show similar product

Other views

APC Rackmountable Smart-UPS Series, 3000 VA, 120 V, 5U

The smart choice for protecting servers and telecom equipment.

SUA3000XL

Extended Double Diamond™ Warranty Available
(Three years for two)

Product Highlights

  • Protects your business-critical servers, voice and data networks, point-of-sale outlets, network switches and equipment, and more.
  • Provides battery backup to guard against power outages and enables safe system shutdowns.
  • Shields your equipment from lightning and surges.
  • Perfect for servers, advanced desktop systems, and networks.
  • Quickswap user-replaceable battery systems make replacing batteries on-site quick and easy.

  • Description

    APC Rackmountable Smart-UPS Series, 3000 VA, 120 V, 5U


    Quick Facts

  • Protects your business-critical servers, voice and data networks, point-of-sale outlets, network switches and equipment, and more.
  • Provides battery backup to guard against power outages and enables safe system shutdowns.
  • Shields your equipment from lightning and surges.
  • Perfect for servers, advanced desktop systems, and networks.
  • Quickswap user-replaceable battery systems make replacing batteries on-site quick and easy.

  • Further Details

  • Intelligent battery management improves reliability and extends battery life.
  • Features the most advanced performance available.
  • Network-grade line conditioning prevents glitches.
  • Full-time EMI/RFI filters neutralize outside interference.
  • Sine-wave power output ensures compatibility with connected equipment.
  • Includes PowerChute® management software.
  • Smart-Slot offers optional management capabilities.
  • Can be used in rackmount or tower configurations.


  • Flash! Crash! Rumble! The wind blows, the lights flicker, and that report you’ve been working on for the past 45 minutes is gone in an instant. Did you save it? Really? Are you sure?

    What happens if lightning strikes the tree on the corner? Will it fry your circuits? How clean is your power? Does it have spikes? Is it dirty with EMI/RFI interference?

    Fortunately, there’s a reliable solution to unreliable power: Smart-UPS from APC. Smart-UPS provides instantaneous backup power for blackouts and brownouts to save your data. It enables you to work through a blackout and safely shut down your system. It can also shut down the system for you.

    Full-time surge protection prevents catastrophic hardware damage. EMI/RFI filtering prevents electrical noise from affecting computer operation or causing data glitches. A site-wiring fault indicator identifies potentially dangerous wiring problems before you even plug in your equipment.

    Smart-UPS provides intelligent battery management and includes PowerChute management software, which provides IT administrators with advanced UPS management. Microprocessor-controlled circuitry monitors battery performance and maximizes battery life.

    Front-panel LEDs indicate On-Line, On Battery, Overload, and Replace Battery. In addition, the system features an LED status display with load and battery bar graphs. An audible alarm sounds when the system is overloaded, running on battery, or when a battery needs to be replaced.

    The Smart-UPS has a SmartSlot, an internal accessory slot that enables you to use SmartSlot performance enhancements, such as environmental controls.

    Includes an RS-232 cable.

    NOTE: This product works with:
    • APC SmartSlot UPS Accessories
    Questions? Contact our FREE Tech Support.


    Technical Specifications for APC Rackmountable Smart-UPS Series, 3000 VA, 120 V, 5U:

    Audible Alarm — On-Battery, Low Battery, Configuration Delays
    Indicators — LED status display with load and battery bar graphs; (4) LEDs: On-Line, On-Battery, Replace Battery, Overload
    Interface Ports — (1) DB9 RS-232, SmartSlot
    Outlets (Output/Input) — (9) NEMA 5-15R, (2) NEMA 5-20R/(1) NEMA L5-30P
    Output Capacity Half/Full Load (Watts/VA) — 1350/2700
    Output Wave Form — Sine wave
    Run Time, Typical (Half Load/Full Load) — 17 min. (1350 watts)/5 min. (2700 watts)
    Surge Energy Rating — 480 joules
    Size — 17"H x 7.7"W x 19.8"D (43.2 x 19.6 x 50.3 cm)
    Weight — 121 lb. (55 kg)
    Warranty — 2 years
    This product works with:
    • APC SmartSlot UPS Accessories
    Questions? Contact our FREE Tech Support.

    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.
