VSW-DVI8X1

Photo may show similar product

Other views

8 x 1 DVI Switch

Switch DVI video from eight sources to a single DVI screen.

VSW-DVI8X1

Extended Double Diamond™ Warranty Available
(3 Additional Year)

Product Highlights

  • Switch on the front panel or from the included IR remote controller.
  • Route video from eight sources to a common digital display.
  • Tested to guarantee resolution up to 1080p without signal degradation.

  • Description

    8 x 1 DVI Switch


    Quick Facts

  • Switch on the front panel or from the included IR remote controller.
  • Route video from eight sources to a common digital display.
  • Tested to guarantee resolution up to 1080p without signal degradation.

  • Further Details

  • Signal enhancer amplifies video as far as 60 feet (18.2 m).
  • HDCP 1.1 and DVI 1.0 compliant.
  • Ideal for use in conference rooms, classrooms, or corporate theaters.

    Route digital DVI video from a whole roomful of digital video sources to a high-definition display with the economical 8 x 1 DVI Switch from Black Box.

    It features a signal enhancer that helps improve signal quality over a long-distance transmission from source to screen. Running digital video over DVI cable longer than 15 feet (1.5 m), you might very well experience signal degradation at the remote screen. This switch, however, is designed to amplify the DVI video signal as far as 60 feet (18.2 m).

    Plus, it's easy to install and operate. Connect all your digital video sources (DVD players, satellite set-top boxes, PCs) to any of the inputs on the switch and connect the output cable to your HD display. Then when you want to switch video ports, simply press a button on the included remote controller or the switch's front panel.

    NOTE: Equipped with DVI-D ports. Supports digital video only.

  • Technical Specifications for 8 x 1 DVI Switch:

    Bandwidth — 1.65 Gbps (single-link)
    CE Approval — Yes
    RoHS — Yes
    Connectors — Input: (8) DVI-D F;
    Output: (1) DVI-D F
    Power — Input: 110/220-VAC, 50/60 Hz;
    Output: 5 VDC
    Size — 2"H x 11"W x 4.5"D (5.1 x 27.9 x 11.4 cm) Weight — 6 lb. (2.7 kg)


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.


    Resources for 8 x 1 DVI Switch:

    Manuals

    • DVI Switch User Manual
      User Manual for VSW-DVI3X1, VSW-DVI4X1, and VSW-DVI8X1 (1)
