SW1032A

Photo may show similar product

Other views

4-to-1 CAT6 10-GbE Manual Switch (ABCD)

Securely access four high-speed, 10-GbE networks!

SW1032A

Extended Double Diamond™ Warranty Available
(3 Additional Year)

Product Highlights

  • Switch between four separate Ethernet networks from one PC without the need to plug and unplug cables.
  • Provides total electrical isolation, so you can safely access secure and public networks from the same desktop.
  • Use in networks from 10BASE-T all the way up to 10-Gigabit Ethernet (10-GbE).


  • Description

    4-to-1 CAT6 10-GbE Manual Switch (ABCD)


    Quick Facts

  • Switch between four separate Ethernet networks from one PC without the need to plug and unplug cables.
  • Provides total electrical isolation, so you can safely access secure and public networks from the same desktop.
  • Use in networks from 10BASE-T all the way up to 10-Gigabit Ethernet (10-GbE).

  • Further Details

  • Proprietary design ensures crosstalk isolation for high-end performance and full 10-GbE support.
  • Simply connect your host device (or shared network link) to Port C (Common port), then connect the different networks or Ethernet devices to the A, B, C, and D ports.
  • Operates manually. Just push a button to switch to another network.
  • No power required.

  • Technical Specifications for 4-to-1 CAT6 10-GbE Manual Switch (ABCD):

    MTBF 100,000 cycles
    Operating Temperature 32 to 158° F (0 to 70° C)
    CE Certified Yes
    Connectors (5) RJ-45
    Power None
    Size 2.75"H x 6.1"W x 6.5"D (7 x 15.5 x 16.5 cm)
    Weight 2 lb. (0.9 kg)


    NOTE: Technical specification weight is the unit weight. It is not the packaged shipping weight. For shipping weight, please contact Black Box customer service at 877-877-2269.
